Mounted Ball Bearings Dodge
| Thuộc tính | Thông tin |
|---|---|
| Tên sản phẩm | Mounted Ball Bearings |
| Tên gọi khác | Gối đỡ bi cầu lắp sẵn |
| Cấu tạo | Vòng bi cầu + housing (lắp ráp sẵn) |
| Loại bi | Bi cầu tự lựa (Self-aligning ball bearing) |
| Vật liệu housing | Gang đúc (Cast Iron) |
| Kiểu lắp | Lắp trục ngang |
| Kiểu bôi trơn | Mỡ bôi trơn sẵn, có đầu tra mỡ |
| Khả năng bù lệch trục | ±2° (tùy dòng) |
| Dải kích thước trục | Hệ inch & hệ mét |
| Tải trọng | Nhẹ đến trung bình |
| Nhiệt độ làm việc | −20°C đến +120°C (tiêu chuẩn) |
Chiết khấu giảm giá
- Mô tả
- Catalogue
- P2B-TB Housings
- F2B-F3B-F4B-FB-FC Housings
- WSTU-NSTU-TP-SCHB-HNG Housings
Mô tả
Gối Đỡ Ổ Bi (Mounted Ball Bearings)
Khi nói đến độ tin cậy và yêu cầu bảo trì thấp, gối đỡ ổ bi Dodge® luôn vượt trội trong ngành. Các dòng gối đỡ ổ bi của chúng tôi được cung cấp với nhiều phương pháp cố định trục đã được kiểm chứng về độ an toàn và độ bám chắc, bao gồm: ốc siết (set screw) với góc 65°, vòng khóa lệch tâm (eccentric locking collar), vòng kẹp đồng tâm D-Lok (concentric clamp collar), và hệ thống lắp đặt Grip Tight® được cấp bằng sáng chế.
Khám phá thêm trong catalog.
PHÂN LOẠI THEO KIỂU HOUSING
| Mã Housing | Thông tin mô tả | Nhóm |
|---|---|---|
| P2B | Pillow Block, 2-Bolt Base | Pillow Block / Base |
| TB | Tapped Base Pillow Block | Pillow Block / Base |
| INS | Insert Bearing | Insert |
| F2B | 2-Bolt Flange | Flange |
| F4B | 4-Bolt Flange | Flange |
| FB | Flanged Bracket | Flange |
| LF | 3-Bolt Light Duty Flange | Light Duty Flange |
| LFT | 2-Bolt Light Duty Flange | Light Duty Flange |
| WSTU | Wide Slot Take-Up | Take-Up |
| NSTU | Narrow Slot Take-Up | Take-Up |
| TP | Top Angle Take-Up | Take-Up |
| HNG | Hanger Bearing | Hanger |
| SCHB | Screw Conveyor Hanger Bearing | Hanger |
Tìm hiểu thêm về:
-
Set Screw
-
Extreme Duty
-
Eccentric Collar
-
Agriculture Duty
-
Grip Tight
-
D-Lok
-
Washdown (FoodSafe™, Ultra Kleen®, và E-Z Kleen®)
Một số mã sản phẩm Gối đỡ ổ bi (Mounted Ball Bearing):
| Part Number (Mã đặt hàng) | Description (Mô tả sản phẩm) |
|---|---|
| 123785 | P2B-SC-030 |
#DodgeBearing #MountedBearings #TaperedRollerBearings #BallBearings #DodgeIndustrial #MechanicalPowerTransmission #IndustrialBearings #BearingSolutions #TypeEBearing
#EXLBearing #TAFBearing #DoubleInterlock #SpecialDutyBearing #HingedCapBearing #TypeKBearing #TypeCBearing #DodgeBallBearing #PillowBlockHousing #FlangeBearing #MountedBallBearings #SphericalRollerBearings #MountedSphericalBearings #DodgeSphericalBearing
Bearing Engineering Catalog: BẤM ĐỂ XEM
Set screw ball bearings
SC and SCU Normal duty pillow blocks
| Standard | Never lube/
sealed for life (-NL) |
|||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 203 | 1/2 | 123830 | P2B-SC-008 | 123932 | P2B-SC-008-NL | 1,1 lbs |
| 203 | 5/8 | 123831 | P2B-SC-010 | 126500 | P2B-SC-010-NL | 1 lbs |
| 203 | 17 mm | 53170 | P2B-SC-17M | @ | P2B-SC-17M-NL | 0,4 kgs |
| 203 | 1/2 | 123753 | P2B-SCU-008 | @ | P2B-SCU-008-NL | 1,2 lbs |
| 204 | 3/4 | 123833 | P2B-SC-012 | @ | P2B-SC-012-NL | 1,9 lbs |
| 204 | 20 mm | 53171 | P2B-SC-20M | @ | P2B-SC-20M-NL | 0,9 kgs |
| 204 | 3/4 | 123754 | P2B-SCU-012 | @ | P2B-SCU-012-NL | 1,3 lbs |
| 205 | 5/8 | 123760 | P2B-SC-010 | @ | P2B-SC-010-NL | 1,2 lbs |
| 205 | 3/4 | 123761 | P2B-SC-012 | @ | P2B-SC-012-NL | 1,4 lbs |
| 205 | 1 | 123762 | P2B-SC-016 | @ | P2B-SC-016-NL | 1,6 lbs |
| 205 | 5/8 | 123755 | P2B-SCU-010 | @ | P2B-SCU-010-NL | 1,2 lbs |
| 205 | 3/4 | 123756 | P2B-SCU-012 | @ | P2B-SCU-012-NL | 1,4 lbs |
| 205 | 1 | 123757 | P2B-SCU-016 | @ | P2B-SCU-016-NL | 1,6 lbs |
| 205 | 25 mm | 53172 | P2B-SC-25M | @ | P2B-SC-25M-NL | 0,7 kgs |
| 206 | 3/4 | 123764 | P2B-SC-012 | @ | P2B-SC-012-NL | 1,7 lbs |
| 206 | 1 | 123765 | P2B-SC-016 | @ | P2B-SC-016-NL | 2 lbs |
| 206 | 1-1/8 | 123766 | P2B-SC-018 | @ | P2B-SC-018-NL | 2 lbs |
| 206 | 3/4 | 123758 | P2B-SCU-012 | @ | P2B-SCU-012-NL | 1,7 lbs |
| 206 | 1 | 123759 | P2B-SCU-016 | @ | P2B-SCU-016-NL | 2 lbs |
| 206 | 30 mm | 53173 | P2B-SC-30M | @ | P2B-SC-30M-NL | 0,9 kgs |
| 207 | 1 | 123768 | P2B-SC-016 | @ | P2B-SC-016-NL | 2,4 lbs |
| 207 | 1-1/8 | 123769 | P2B-SC-018 | @ | P2B-SC-018-NL | 2,5 lbs |
| 207 | 1-1/4 | 123770 | P2B-SC-020 | @ | P2B-SC-020-NL | 2,6 lbs |
| 207 | 1-3/8 | 123771 | P2B-SC-022 | @ | P2B-SC-022-NL | 2,7 lbs |
| 207 | 1 | 123763 | P2B-SCU-016 | @ | P2B-SCU-016-NL | 2,4 lbs |
| 207 | 1-1/8 | 123767 | P2B-SCU-018 | @ | P2B-SCU-018-NL | 2,5 lbs |
| 207 | 1-1/4 | 123772 | P2B-SC-020 | @ | P2B-SC-020-NL | 2,6 lbs |
| 207 | 1-3/8 | 123773 | P2B-SC-022 | @ | P2B-SC-022-NL | 2,7 lbs |
| 207 | 35 mm | 53174 | P2B-SC-35M | @ | P2B-SC-35M-NL | 1,2 kgs |
| 208 | 1 | 123775 | P2B-SC-016 | @ | P2B-SC-016-NL | 3,2 lbs |
| 208 | 1-1/2 | 123776 | P2B-SC-024 | @ | P2B-SC-024-NL | 3,3 lbs |
| 208 | 1-1/4 | 123777 | P2B-SC-020 | @ | P2B-SC-020-NL | 3,5 lbs |
| 208 | 1-3/8 | 123778 | P2B-SC-022 | @ | P2B-SC-022-NL | 3,5 lbs |
| 208 | 1-3/4 | 123779 | P2B-SC-028 | @ | P2B-SC-028-NL | 3,8 lbs |
| 208 | 40 mm | 53175 | P2B-SC-40M | @ | P2B-SC-40M-NL | 1,6 kgs |
| 209 | 1-1/2 | 123780 | P2B-SC-024 | @ | P2B-SC-024-NL | 4,3 lbs |
| 209 | 1-3/4 | 123781 | P2B-SC-028 | @ | P2B-SC-028-NL | 4,5 lbs |
| 209 | 2 | 123782 | P2B-SC-032 | @ | P2B-SC-032-NL | 4,8 lbs |
| 209 | 45 mm | @ | P2B-SC-45M | @ | P2B-SC-45M-NL | 2 kgs |
| 210 | 1-3/4 | 123784 | P2B-SC-028 | @ | P2B-SC-028-NL | 6 lbs |
| 210 | 1-7/8 | 123785 | P2B-SC-030 | @ | P2B-SC-030-NL | 6,1 lbs |
| 210 | 2 | 123786 | P2B-SC-032 | @ | P2B-SC-032-NL | 6,3 lbs |
| 210 | 50 mm | @ | P2B-SC-50M | @ | P2B-SC-50M-NL | 2,8 kgs |
| 211 | 65 mm | @ | P2B-SC-65M | @ | P2B-SC-65M-NL | 4,5 kgs |
| 212 | 75 mm | @ | P2B-SC-75M | @ | P2B-SC-75M-NL | 7,8 kgs |
| 213 | 80 mm | @ | P2B-SC-80M | @ | P2B-SC-80M-NL | 9,9 kgs |
| 214 | 90 mm | @ | P2B-SC-90M | @ | P2B-SC-90M-NL | 13,6 kgs |
@ Assembled to order
Set screw ball bearings
SCB Normal duty pillow blocks
| Series | Size | Part number | Description | Weight |
| 203 | 1/2 | 123830 | P2B-SC-008 | 1.1 lbs |
| 203 | 5/8 | 123831 | P2B-SC-010 | 1.0 lbs |
| 203 | 17 mm | 53170 | P2B-SC-17M | 0.4 kgs |
| 204 | 1/2 | 123854 | P2B-SCB-008L | 1.6 lbs |
| 204 | 5/8 | 123855 | P2B-SCB-010L | 1.5 lbs |
| 204 | 3/4 | 123860 | P2B-SCB-012 | 1.4 lbs |
| 204 | 20 mm | 124941 | P2B-SCB-20M | 0.7 kgs |
| 205 | 7/8 | 123861 | P2B-SCB-014 | 1.8 lbs |
| 205 | 15/16 | 123862 | P2B-SCB-015 | 1.7 lbs |
| 205 | 1 | 123863 | P2B-SCB-100 | 1.6 lbs |
| 205 | 25 mm | 125768 | P2B-SCB-25M | 0.07 kgs |
| 206 | 1-1/16 | 123856 | P2B-SCB-101 | 2.8 lbs |
| 206 | 1-1/8 | 123864 | P2B-SCB-102 | 2.7 lbs |
| 206 | 1-3/16 | 123865 | P2B-SCB-103 | 2.6 lbs |
| 206 | 1-1/4 | 123171 | P2B-SCB-104S | 2.5 lbs |
| 206 | 30 mm | 125760 | P2B-SCB-30M | 1.1 kgs |
| 207 | 1–1/4 | 123866 | P2B-SCB-104 | 4.5 lbs |
| 207 | 1–5/16 | 123857 | P2B-SCB-105 | 4.4 lbs |
| 207 | 1–3/8 | 123867 | P2B-SCB-106 | 4.3 lbs |
| 207 | 1–7/16 | 123868 | P2B-SCB-107 | 4.2 lbs |
| 207 | 35 mm | 124944 | P2B-SCB-35M | 1.5 kgs |
| 208 | 1-1/2 | 123869 | P2B-SCB-108 | 5.4 lbs |
| 208 | 1-5/8 | 123858 | P2B-SCB-110 | 5.3 lbs |
| 208 | 40 mm | 125856 | P2B-SCB-40M | 2.2 kgs |
| 209 | 1-5/8 | 68760 | P2B-SCB-110L | 6.6 lbs |
| 209 | 1-11/16 | 123870 | P2B-SCB-111 | 6.4 lbs |
| 209 | 1-3/4 | 123871 | P2B-SCB-112 | 6.2 lbs |
| 209 | 45 mm | 51878 | P2B-SCB-45M | 2.2 kgs |
| 210 | 1-15/16 | 123872 | P2B-SCB-115 | 7.8 lbs |
| 210 | 2 | 123873 | P2B-SCB-200 | 7.0 lbs |
| 210 | 50 mm | 51879 | P2B-SCB-50M | 2.6 kgs |
| 211 | 2 | 57603 | P2B-SCB-200L | 9.0 lbs |
| 211 | 2-3/16 | 123874 | P2B-SCB-203 | 8.9 lbs |
| 211 | 2-1/4 | 123589 | P2B-SCB-204 | 8.8 lbs |
| 211 | 55 mm | 124943 | P2B-SCB-55M | 3.3 kgs |
| 212 | 2-1/4 | 68361 | P2B-SCB-204L | 10.8 lbs |
| 212 | 2-7/16 | 123875 | P2B-SCB-207 | 10.2 lbs |
| 212 | 60 mm | 51880 | P2B-SCB-60M | 4.2 kgs |
| 215 | 2-15/16 | 123727 | P2B-SCB-215 | 20.5 lbs |
| 215 | 75 mm | @ | P2B-SCB-75M | 7.9 kgs |
@ Assembled to order
Set screw ball bearings
SCH-E Expansion normal duty pillow blocks
| Expansion | Non-expansion | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 205 | 1 | 64637 | P2B-SCH-100-E | 126147 | P2B-SCM-100 | 2.8 lbs |
| 205 | 25 mm | 73418 | P2B-SCH-25M-E | 125925 | P2B-SCM-25M | 1.2 kgs |
| 206 | 1-1/16 | @ | P2B-SCH-101-E | — | — | 4.8 lbs |
| 206 | 1-1/8 | @ | P2B-SCH-102-E | — | — | 4.7 lbs |
| 206 | 3/16 | 126405 | P2B-SCH-103-E | 126147 | P2B-SCM-103 | 4.6 lbs |
| 206 | 1-1/4 | 53183 | P2B-SCH-104S-E | 123810 | P2B-SC-104 | 4.5 lbs |
| 206 | 30 mm | 53021 | P2B-SCH-30M-E | 125926 | P2B-SCM-30M | 1.9 kgs |
| 207 | 1-1/4 | @ | P2B-SCH-104-E | — | — | 6.7 lbs |
| 207 | 1-5/16 | @ | P2B-SCH-105-E | — | — | 6.6 lbs |
| 207 | 1-3/8 | @ | P2B-SCH-106-E | — | — | 6.5 lbs |
| 207 | 1-7/16 | 126406 | P2B-SCH-107-E | 126810 | P2B-SCM-107 | 6.4 lbs |
| 207 | 35 mm | 73358 | P2B-SCH-35M-E | 125927 | P2B-SCM-35M | 2.7 kgs |
| 209 | 5/8 | @ | P2B-SCH-110L-E | — | — | 6.4 lbs |
| 209 | 1-11/16 | 57414 | P2B-SCH-111-E | 126812 | P2B-SCM-111 | 6.3 lbs |
| 209 | 1-3/4 | 74926 | P2B-SCH-112-E | 126813 | P2B-SCM-112 | 6.2 lbs |
| 209 | 45 mm | 56481 | P2B-SCH-45M-E | 125929 | P2B-SCM-45M | 2.6 kgs |
| 210 | 1-15/16 | 126407 | P2B-SCH-115-E | 126814 | P2B-SCM-115 | 9.8 lbs |
| 210 | 2 | 52224 | P2B-SCH-200-E | 126815 | P2B-SCM-200 | 9.7 lbs |
| 210 | 50 mm | 56483 | P2B-SCH-50M-E | 125930 | P2B-SCM-50M | 4.0 kgs |
| 211 | 2-3/16 | 126408 | P2B-SCH-203-E | 126816 | P2B-SCM-203 | 14.3 lbs |
| 211 | 2-1/4 | 68800 | P2B-SCH-204-E | 126817 | P2B-SCM-204 | 14.2 lbs |
| 211 | 55 mm | 53025 | P2B-SCH-55M-E | 125931 | P2B-SCM-55M | 5.9 kgs |
| 212 | 2-7/16 | 126409 | P2B-SCH-207-E | 126818 | P2B-SCM-207 | 16.6 lbs |
| 212 | 60 mm | @ | P2B-SCH-60M-E | — | — | 6.8 kgs |
@ Assembled to order
Set screw VSC ball bearings
VSC and VSCU Intermediate duty pillow blocks
| Standard | Never lube/
sealed for life (-NL) |
|||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 203 | 1/2 | 125500 | P2B-VSC-008 | 49887 | P2B-VSC-008-NL | 1.1 lbs |
| 203 | 5/8 | 125501 | P2B-VSC-010 | @ | P2B-VSC-010-NL | 1.0 lbs |
| 203 | 17 mm | @ | P2B-VSC-17M | @ | P2B-VSC-17M-NL | 0.5 lbs |
| 203 (VSCU) | 1/2 | 125513 | P2B-VSCU-008 | @ | P2B-VSCU-008-NL | 1.2 lbs |
| 203 (VSCU) | 5/8 | 125514 | P2B-VSCU-010 | @ | P2B-VSCU-010-NL | 1.1 lbs |
| 203 (VSCU) | 17 mm | 125685 | P2B-VSCU-17M | @ | P2B-VSCU-17M-NL | 0.6 lbs |
| 204 | 3/4 | 123580 | P2B-VSC-012 | 54495 | P2B-VSC-012-NL | 1.4 lbs |
| 204 | 20 mm | 125686 | P2B-VSC-20M | @ | P2B-VSC-20M-NL | 0.6 lbs |
| 205 | 7/8 | 125502 | P2B-VSC-014 | @ | P2B-VSC-014-NL | 1.8 lbs |
| 205 | 15/16 | 125503 | P2B-VSC-015 | @ | P2B-VSC-015-NL | 1.7 lbs |
| 205 | 1 | 123581 | P2B-VSC-100 | 123590 | P2B-VSC-100-NL | 1.6 lbs |
| 205 | 25 mm | 125687 | P2B-VSC-25M | @ | P2B-VSC-25M-NL | 0.8 lbs |
| 206 | 1-1/8 | 125504 | P2B-VSC-102 | @ | P2B-VSC-102-NL | 2.7 lbs |
| 206 | 1-3/16 | 123582 | P2B-VSC-103 | 64691 | P2B-VSC-103-NL | 2.6 lbs |
| 206 | 1-1/4 | 123589 | P2B-VSC-104S | @ | P2B-VSC-104S-NL | 2.5 lbs |
| 206 | 30 mm | 125751 | P2B-VSC-30M | @ | P2B-VSC-30M-NL | 1.2 lbs |
| 206 (VSCU) | 1-1/8 | 125515 | P2B-VSCU-102 | @ | P2B-VSCU-102-NL | 2.8 lbs |
| 206 (VSCU) | 1-3/16 | 123604 | P2B-VSCU-103 | 50845 | P2B-VSCU-103-NL | 2.7 lbs |
| 206 (VSCU) | 1-1/4 | 123606 | P2B-VSCU-104S | @ | P2B-VSCU-104S-NL | 2.6 lbs |
| 206 (VSCU) | 30 mm | 125688 | P2B-VSCU-30M | @ | P2B-VSCU-30M-NL | 1.3 lbs |
| 207 | 1-1/4 | 123583 | P2B-VSC-104 | 51889 | P2B-VSC-104-NL | 4.5 lbs |
| 207 | 1-3/8 | 125505 | P2B-VSC-106 | @ | P2B-VSC-106-NL | 4.3 lbs |
| 207 | 1-7/16 | 123584 | P2B-VSC-107 | 50838 | P2B-VSC-107-NL | 4.2 lbs |
| 207 | 35 mm | 125689 | P2B-VSC-35M | 67664 | P2B-VSC-35M-NL | 2.0 lbs |
| 208 | 1-1/2 | 123585 | P2B-VSC-108 | 51890 | P2B-VSC-108-NL | 5.4 lbs |
| 208 | 40 mm | @ | P2B-VSC-40M | @ | P2B-VSC-40M-NL | 2.5 lbs |
| 209 | 1-11/16 | 125506 | P2B-VSC-111 | @ | P2B-VSC-111-NL | 6.4 lbs |
| 209 | 1-3/4 | 124933 | P2B-VSC-112 | @ | P2B-VSC-112-NL | 6.2 lbs |
| 209 | 45 mm | 125691 | P2B-VSC-45M | @ | P2B-VSC-45M-NL | 3.0 lbs |
| 210 | 1-15/16 | 123586 | P2B-VSC-115 | 53662 | P2B-VSC-115-NL | 7.2 lbs |
| 210 | 2 | 123587 | P2B-VSC-200 | @ | P2B-VSC-200-NL | 7.0 lbs |
| 210 | 50 mm | 125692 | P2B-VSC-50M | @ | P2B-VSC-50M-NL | 3.3 lbs |
| 211 | 2 | 123593 | P2B-VSC-200L | 49784 | P2B-VSC-200L-NL | 9.0 lbs |
| 211 | 2-3/16 | 123588 | P2B-VSC-203 | @ | P2B-VSC-203-NL | 8.9 lbs |
| 211 | 55 mm | 125693 | P2B-VSC-55M | @ | P2B-VSC-55M-NL | 4.2 lbs |
@ Assembled to order
Set screw VSC ball bearings
VSCB Intermediate duty pillow blocks
| Standard | Never lube/
sealed for life (-NL) |
|||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 203 | 1/2 | 125500 | P2B-VSC-008 | @ | P2B-VSC-008-NL | 1.1 lbs |
| 203 | 5/8 | 125501 | P2B-VSC-010 | @ | P2B-VSC-010-NL | 1.0 lbs |
| 203 | 17 mm | @ | P2B-VSC-17M | @ | P2B-VSC-17M-NL | 0.5 kgs |
| 204 | 3/4 | 123595 | P2B-VSCB-012 | 50833 | P2B-VSCB-012-NL | 1.4 lbs |
| 204 | 20 mm | @ | P2B-VSCB-20M | @ | P2B-VSCB-20M-NL | 0.6 kgs |
| 205 | 7/8 | 125508 | P2B-VSCB-014 | @ | P2B-VSCB-014-NL | 1.8 lbs |
| 205 | 15/16 | 125509 | P2B-VSCB-015 | @ | P2B-VSCB-015-NL | 1.7 lbs |
| 205 | 1 | 123596 | P2B-VSCB-100 | 50828 | P2B-VSCB-100-NL | 1.6 lbs |
| 205 | 25 mm | @ | P2B-VSCB-25M | @ | P2B-VSCB-25M-NL | 0.8 kgs |
| 206 | 1-1/8 | 125510 | P2B-VSCB-102 | @ | P2B-VSCB-102-NL | 2.7 lbs |
| 206 | 1-3/16 | 123597 | P2B-VSCB-103 | 50829 | P2B-VSCB-103-NL | 2.6 lbs |
| 206 | 1-1/4 | 123605 | P2B-VSCB-104S | @ | P2B-VSCB-104S-NL | 2.5 lbs |
| 206 | 30 mm | @ | P2B-VSCB-30M | @ | 2B-VSCB-30M-NL | 1.2 kgs |
| 207 | 1-1/4 | 123598 | P2B-VSCB-104 | @ | P2B-VSCB-104-NL | 4.5 lbs |
| 207 | 1-3/8 | 125511 | P2B-VSCB-106 | @ | P2B-VSCB-106-NL | 4.3 lbs |
| 207 | 1-7/16 | 123599 | P2B-VSCB-107 | 50830 | P2B-VSCB-107-NL | 4.2 lbs |
| 207 | 35 mm | @ | P2B-VSCB-35M | @ | P2B-VSCB-35M-NL | 2.0 kgs |
| 208 | 1-1/2 | 123600 | P2B-VSCB-108 | @ | P2B-VSCB-108-NL | 5.4 lbs |
| 208 | 40 mm | 125690 | P2B-VSCB-40M | @ | P2B-VSCB-40M-NL | 2.5 kgs |
| 209 | 1-11/16 | 125512 | P2B-VSCB-111 | 50848 | P2B-VSCB-111-NL | 6.4 lbs |
| 209 | 1-3/4 | 125507 | P2B-VSCB-112 | @ | P2B-VSCB-112-NL | 6.2 lbs |
| 209 | 45 mm | @ | P2B-VSCB-45M | 68428 | P2B-VSCB-45M-NL | 3.0 kgs |
| 210 | 1-15/16 | 123601 | P2B-VSCB-115 | @ | P2B-VSCB-115-NL | 7.2 lbs |
| 210 | 2 | 123602 | P2B-VSCB-200 | @ | P2B-VSCB-200-NL | 7.0 lbs |
| 210 | 50 mm | @ | P2B-VSCB-50M | @ | P2B-VSCB-50M-NL | 3.3 kgs |
| 211 | 2 | 123607 | P2B-VSCB-200L | @ | P2B-VSCB-200L-NL | 9.0 lbs |
| 211 | 2-3/16 | 123603 | P2B-VSCB-203 | 50831 | P2B-VSCB-203-NL | 8.9 lbs |
| 211 | 55 mm | @ | P2B-VSCB-55M | @ | P2B-VSCB-55M-NL | 4.2 kgs |
@ Assembled to order
D-Lok ball bearings
DLB Normal duty pillow blocks
| Series | Size | Part number | Description | Weight |
| 204 | 3/4 | 128721 | P2B-DLB-012 | 2.1 lbs |
| 204 | 20 mm | @ | P2B-DLB-20M | 1.0 kgs |
| 205 | 7/8 | 128722 | P2B-DLB-014 | 2.3 lbs |
| 205 | 15/16 | 128723 | P2B-DLB-015 | 2.3 lbs |
| 205 | 1 | 128724 | P2B-DLB-100 | 2.3 lbs |
| 205 | 25 mm | 62143 | P2B-DLB-25M | 1.1 kgs |
| 206 | 1-1/8 | 128725 | P2B-DLB-102 | 3.8 lbs |
| 206 | 1-3/16 | 128726 | P2B-DLB-103 | 3.7 lbs |
| 206 | 1-1/4 | 128727 | P2B-DLB-104S | 3.7 lbs |
| 206 | 30 mm | @ | P2B-DLB-30M | 1.7 kgs |
| 207 | 1-1/4 | 128728 | P2B-DLB-104 | 4.9 lbs |
| 207 | 1-3/8 | 128729 | P2B-DLB-106 | 4.9 lbs |
| 207 | 1-7/16 | 128730 | P2B-DLB-107 | 4.8 lbs |
| 207 | 35 mm | @ | P2B-DLB-35M | 2.2 kgs |
| 208 | 1-1/2 | 128710 | P2B-DLB-108 | 6.0 lbs |
| 208 | 40 mm | 126605 | P2B-DLB-40M | 2.7 kgs |
| 209 | 1-5/8 | 128731 | P2B-DLB-110L | 6.8 lbs |
| 209 | 1-11/16 | 128732 | P2B-DLB-111 | 6.8 lbs |
| 209 | 1-3/4 | 128733 | P2B-DLB-112 | 6.7 lbs |
| 209 | 45 mm | @ | P2B-DLB-45M | 3.1 kgs |
| 210 | 1-15/16 | 128734 | P2B-DLB-115 | 8.5 lbs |
| 210 | 2 | 128735 | P2B-DLB-200 | 8.4 lbs |
| 210 | 50 mm | @ | P2B-DLB-50M | 3.9 kgs |
| 211 | 2 | 128736 | P2B-DLB-200L | 12.2 lbs |
| 211 | 2-3/16 | 128738 | P2B-DLB-203 | 10.3 lbs |
| 211 | 55 mm | @ | P2B-DLB-55M | 5.6 kgs |
| 212 | 2-1/4 | 128739 | P2B-DLB-204L | 17.5 lbs |
| 212 | 2-7/16 | 128741 | P2B-DLB-207 | 14.8 lbs |
| 212 | 60 mm | @ | P2B-DLB-60M | 7.0 kgs |
@ Assembled to order
D-Lok ball bearings
DLM Medium duty pillow blocks
| Series | Size | Part number | Description | Weight |
| 206 (DLMU) | 1 | 128823 | P2B-DLMU-100 | 4.2 |
| 206 | 1-3/16 | 128824 | P2B-DLM-103 | 5.6 |
| 207 | 1-1/4 | 128707 | P2B-DL-104 | 4.9 |
| 207 | 1-7/16 | 128825 | P2B-DLM-107 | 7.2 |
| 208 | 35 mm | 126639 | P2B-DLM-35M | 3.2 |
| 208 | 1-1/2 | 128826 | P2B-DLM-108 | 9.2 |
| 209 | 1-5/8 | 128711 | P2B-DL-110L | 6.8 |
| 209 | 1-11/16 | 128827 | P2B-DLM-111 | 10.1 |
| 210 | 1-3/4 | 128828 | P2B-DLM-112 | 10.1 |
| 210 (DLMB) | 1-11/16 | 068373 | P2B-DLMB-111 | 12.3 |
| 210 | 1-15/16 | 128829 | P2B-DLM-115 | 12.2 |
| 211 | 2 | 128830 | P2B-DLM-200 | 12.2 |
| 211 | 50 mm | 058997 | P2B-DLM-50M | 5.5 |
| 211 | 2-3/16 | 128831 | P2B-DLM-203 | 17.5 |
| 212 | 2-1/4 | 128832 | P2B-DLM-204 | 17.5 |
| 212 | 2-7/16 | 128833 | P2B-DLM-207 | 19.4 |
| 214 | 2-1/2 | 128834 | P2B-DLM-208 | 19.4 |
| 214 | 65 mm | 126640 | P2B-DLM-65M | 6.9 |
| 215 | 2-11/16 | 128696 | P2B-DLM-211 | 24.9 |
| 216 | 2-15/16 | 128697 | P2B-DLM-215 | 25.4 |
| 218 | 3-7/16 | 128698 | P2B-DLM-307 | 34.9 |
@Assemble to order
D-Lok ball bearings
DLH-E Expansion and DLH non-expansion normal duty pillow blocks
| Series | Size | Expansion | Non-Expansion | Weight | ||
| Part number | Description | Part number | Description | |||
| 205 | 1 | 76714 | P2B-DLH-100-E | @ | P2B-DLM-100 | 3.5 |
| 205 | 25 mm | 075048 | P2B-DLH-25M-E | — | — | 1.6 |
| 205 | 1-1/8 | @ | P2B-DLH-102-E | — | — | 5 |
| 205 | 1-3/16 | 126450 | P2B-DLH-103-E | 128824 | P2B-DLM-103 | 5 |
| 206 | 1-1/4 | @ | P2B-DLH-104S-E | 128707 | P2B-DL-104 | 5 |
| 206 | 30 mm | 075049 | P2B-DLH-30M-E | – | – | 1.5 |
| 206 | 1-1/4 | @ | P2B-DLH-104-E | — | — | 6.9 |
| 206 | 1-3/8 | @ | P2B-DLH-106-E | — | — | 6.9 |
| 207 | 1-7/16 | 126451 | P2B-DLH-107-E | 128825 | P2B-DLM-107 | 6.9 |
| 207 | 35 mm | 054455 | P2B-DLH-35M-E | 126639 | P2B-DLM-35M | 2.1 |
| 207 | 1-5/8 | @ | P2B-DLH-110L-E | — | — | 9.2 |
| 207 | 1-11/16 | 059882 | P2B-DLH-111-E | 68373 | P2B-DLMB-111 | 9.2 |
| 209 | 1-3/4 | @ | P2B-DLH-112-E | — | P2B-DLM-112 | 9.2 |
| 209 | 45 mm | 075051 | P2B-DLH-45M-E | — | — | 2.8 |
| 209 | 1-15/16 | 126452 | P2B-DLH-115-E | 128829 | P2B-DLM-115 | 10.8 |
| 210 | 2 | 056676 | P2B-DLH-200-E | 128830 | P2B-DLM-200 | 10.8 |
| 210 | 50 mm | 068061 | P2B-DLH-50M-E | 58997 | P2B-DLM-50M | 3.3 |
| 210 | 2-3/16 | 126453 | P2B-DLH-203-E | 128831 | P2B-DLM-203 | 15.7 |
| 211 | 55 mm | 075052 | P2B-DLH-55M-E | — | — | 4.8 |
| 211 | 2-7/16 | 126454 | P2B-DLH-207-E | 128833 | P2B-DLM-2 |
@Assemble to order
D-Lok ball bearings
DL Normal duty 2-bolt flange bearings
| Series | Size | Standard | Never lube.
Sealed for life (-NL) |
Weight | ||
| Part number | Description | Part number | Description | Weight (lbs) | ||
| 205 | 3/4 | 128757 | F2B-DL-012 | 52931 | F2B-DL-012-NL | 1.4 |
| 205 | 20 mm | 126611 | F2B-DL-20M | 65632 | F2B-DL-20M-NL | 0.6 |
| 205 | 7/8 | 128758 | F2B-DL-014 | @ | F2B-DL-014-NL | 1.8 |
| 205 | 15/16 | 128759 | F2B-DL-015 | 59850 | F2B-DL-015-NL | 1.8 |
| 205 | 1 | 128760 | F2B-DL-100 | 52984 | F2B-DL-100-NL | 1.8 |
| 205 | 25 mm | 126612 | F2B-DL-25M | 59680 | F2B-DL-25M-NL | 0.8 |
| 205 | 1-1/8 | 128761 | F2B-DL-102 | @ | F2B-DL-102-NL | 2.4 |
| 205 | 1-3/16 | 128762 | F2B-DL-103 | 67970 | F2B-DL-103-NL | 2.4 |
| 206 | 1-1/4 | 128763 | F2B-DL-104S | 68643 | F2B-DL-104S-NL | 2.3 |
| 206 | 30 mm | 126613 | F2B-DL-30M | 62438 | F2B-DL-30M-NL | 1.1 |
| 206 | 1-1/4 | 128764 | F2B-DL-104 | 58625 | F2B-DL-104-NL | 3.5 |
| 206 | 1-3/8 | 128765 | F2B-DL-106 | @ | F2B-DL-106-NL | 3.5 |
| 207 | 1-7/16 | 128766 | F2B-DL-107 | 56961 | F2B-DL-107-NL | 3.4 |
| 207 | 35 mm | 126614 | F2B-DL-35M | 65658 | F2B-DL-35M-NL | 1.6 |
| 207 | 1-1/2 | 128767 | F2B-DL-108 | 59857 | F2B-DL-108-NL | 4.8 |
| 208 | 40 mm | 126615 | F2B-DL-40M | 62379 | F2B-DL-40M-NL | 2.2 |
| 208 | 1-5/8 | 128768 | F2B-DL-110L | @ | F2B-DL-110L-NL | 5.2 |
| 208 | 1-11/16 | 128769 | F2B-DL-111 | 56962 | F2B-DL-111-NL | 5.2 |
| 208 | 1-3/4 | 128770 | F2B-DL-112 | 54142 | F2B-DL-112-NL | 5.2 |
| 208 | 45 mm | 126616 | F2B-DL-45M | @ | F2B-DL-45M-NL | 2.4 |
| 208 | 1-15/16 | 128771 | F2B-DL-115 | 56967 | F2B-DL-115-NL | 6 |
| 210 | 2 | 128772 | F2B-DL-200 | @ | F2B-DL-200-NL | 5.9 |
| 210 | 50 mm | 126617 | F2B-DL-50M | 65605 | F2B-DL-50M-NL | 2.7 |
| 210 | 2 | 128842 | F2B-DLM-200 | @ | F2B-DLM-200-NL | 9.1 |
| 211 | 2-3/16 | 128774 | F2B-DL-203 | @ | F2B-DL-203-NL | 9.1 |
| 211 | 55 mm | 126618 | F2B-DL-55M | @ | F2B-DL-55M-NL | 4.1 |
@Assemble to order
Set screw ball bearings
SC Normal duty 2-bolt flange bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 203 | 1/2 | 124198 | F2B-SC-008 | @ | F2B-SC-008-NL | 0.8 lbs |
| 203 | 5/8 | 124199 | F2B-SC-010 | 124256 | F2B-SC-010-NL | 0.7 lbs |
| 203 | 17 mm | 125875 | F2B-SC-17M | @ | F2B-SC-17M-NL | 0.3 kgs |
| 204 | 1/2 | 124166 | F2B-SC-008L | 52220 | F2B-SC-008L-NL | 1.6 lbs |
| 204 | 5/8 | 124167 | F2B-SC-010L | 124176 | F2B-SC-010L-NL | 1.5 lbs |
| 204 | 3/4 | 124170 | F2B-SC-012 | 124175 | F2B-SC-012-NL | 1.4 lbs |
| 204 | 20 mm | 125876 | F2B-SC-20M | 50119 | F2B-SC-20M-NL | 0.5 kgs |
| 205 | 7/8 | 124171 | F2B-SC-014 | 126516 | F2B-SC-014-NL | 1.6 lbs |
| 205 | 15/16 | 124172 | F2B-SC-015 | 73662 | F2B-SC-015-NL | 1.5 lbs |
| 205 | 1 | 124173 | F2B-SC-100 | 124174 | F2B-SC-100-NL | 1.4 lbs |
| 205 | 25 mm | 125877 | F2B-SC-25M | 124785 | F2B-SC-25M-NL | 0.6 kgs |
| 206 | 1-1/16 | 124410 | F2B-SC-101 | @ | F2B-SC-101-NL | 2.3 lbs |
| 206 | 1-1/8 | 124274 | F2B-SC-102 | 65766 | F2B-SC-102-NL | 2.2 lbs |
| 206 | 1-3/16 | 124275 | F2B-SC-103 | 124614 | F2B-SC-103-NL | 2.1 lbs |
| 206 | 1-1/4 | 123172 | F2B-SC-104S | 64656 | F2B-SC-104S-NL | 2.0 lbs |
| 206 | 30 mm | 125878 | F2B-SC-30M | 126102 | F2B-SC-30M-NL | 1.0 kgs |
| 207 | 1-1/4 | 124276 | F2B-SC-104 | 126518 | F2B-SC-104-NL | 3.5 lbs |
| 207 | 1-5/16 | 124411 | F2B-SC-105 | @ | F2B-SC-105-NL | 3.4 lbs |
| 207 | 1-3/8 | 124277 | F2B-SC-106 | 126519 | F2B-SC-106-NL | 3.2 lbs |
| 207 | 1-7/16 | 124278 | F2B-SC-107 | 124618 | F2B-SC-107-NL | 3.1 lbs |
| 207 | 35 mm | 125879 | F2B-SC-35M | 67663 | F2B-SC-35M-NL | 1.5 kgs |
| 208 | 1-1/2 | 124268 | F2B-SC-108 | 52011 | F2B-SC-108-NL | 4.1 lbs |
| 208 | 1-5/8 | 124412 | F2B-SC-110 | @ | F2B-SC-110-NL | 4.0 lbs |
| 208 | 40 mm | 125880 | F2B-SC-40M | 126042 | F2B-SC-40M-NL | 1.8 kgs |
| 209 | 1-5/8 | 125171 | F2B-SC-110L | @ | F2B-SC-110L-NL | 5.2 lbs |
| 209 | 1-11/16 | 124279 | F2B-SC-111 | 67666 | F2B-SC-111-NL | 5.0 lbs |
| 209 | 1-3/4 | 124413 | F2B-SC-112 | 126521 | F2B-SC-112-NL | 5.0 lbs |
| 209 | 1-13/16 | 124280 | F2B-SC-113 | 67019 | F2B-SC-113-NL | 4.9 lbs |
| 209 | 45 mm | 125881 | F3B-SC-45M | @ | F2B-SC-45M-NL | 4.7 kgs |
| 210 | 1-15/16 | 124269 | F2B-SC-115 | 126522 | F2B-SC-115-NL | 5.4 lbs |
| 210 | 2 | 124270 | F2B-SC-200 | 126523 | F2B-SC-200-NL | 5.2 lbs |
| 210 | 50 mm | 125882 | F2B-SC-50M | 124282 | F2B-SC-50M-NL | 2.5 kgs |
| 211 | 2 | 126293 | F2B-SCM-200 | 65595 | F2B-SCM-200-NL | 6.7 lbs |
| 211 | 2-3/16 | 124034 | F2B-SC-203 | 67959 | F2B-SC-203-NL | 6.5 lbs |
| 211 | 2-1/4 | 124373 | F2B-SC-204 | @ | F2B-SC-204-NL | 6.3 lbs |
| 211 | 55 mm | 124942 | F2B-SC-55M | @ | F2B-SC-55M-NL | 3.0 kgs |
| 212 | 2-1/4 | @ | F2B-SCM-204 | 93733 | F2B-SCM-204-NL | 7.4 lbs |
| 212 | 2-7/16 | 53175 | F2B-SC-207 | 49437 | F2B-SC-207-NL | 7.0 lbs |
| 212 | 60 mm | 53883 | F2B-SC-60M | @ | F2B-SC-60M-NL | 3.4 kgs |
@ Assembled to order
Set screw ball bearings
SCM Medium duty 2-Bolt flange bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 206 | 1 | 126284 | F2B-SCM-100 | @ | F2B-SCM-100-NL | 2.4 lbs |
| 206 | 25 mm | 125954 | F2B-SCM-25M | @ | F2B-SCM-25M-NL | 1.0 kgs |
| 207 | 1-3/16 | 126285 | F2B-SCM-103 | @ | F2B-SCM-103-NL | 3.6 lbs |
| 207 | 1-1/4 | 124276 | F2B-SC-104 | 126518 | F2B-SC-104-NL | 3.5 lbs |
| 207 | 30 mm | 125955 | F2B-SCM-30M | @ | F2B-SCM-30M-NL | 1.6 kgs |
| 208 | 1-7/16 | 126287 | F2B-SCM-107 | @ | F2B-SCM-107-NL | 4.1 lbs |
| 208 | 35 mm | 125956 | F2B-SCM-35M | @ | F2B-SCM-35M-NL | 1.9 kgs |
| 209 | 1-1/2 | 126288 | F2B-SCM-108 | 126536 | F2B-SCM-108-NL | 5.3 lbs |
| 209 | 1-5/8 | 125171 | F2B-SC-110L | @ | F2B-SC-110L-NL | 5.2 lbs |
| 209 | 40 mm | 125957 | F2B-SCM-40M | 67674 | F2B-SCM-40M-NL | 2.3 kgs |
| 210 | 1-11/16 | 126289 | F2B-SCM-111 | @ | F2B-SCM-111-NL | 5.8 lbs |
| 210 | 1-3/4 | 126290 | F2B-SCM-112 | @ | F2B-SCM-112-NL | 5.6 lbs |
| 210 | 45 mm | 125958 | F2B-SCM-45M | @ | F2B-SCM-45M-NL | 2.6 kgs |
| 211 | 1-15/16 | 126292 | F2B-SCM-115 | @ | F2B-SCM-115-NL | 6.7 lbs |
| 211 | 2 | 126293 | F2B-SCM-200 | 65595 | F2B-SCM-200-NL | 6.5 lbs |
| 211 | 50 mm | 125960 | F2B-SCM-50M | @ | F2B-SCM-50M-NL | 2.9 kgs |
| 212 | 2-3/16 | 62746 | F2B-SCM-203 | @ | F2B-SCM-203-NL | 7.4 lbs |
| 212 | 2-1/4 | 73492 | F2B-SCM-204 | @ | F2B-SCM-204-NL | 7.2 lbs |
| 212 | 55 mm | @ | F2B-SCM-55M | @ | F2B-SCM-55M-NL | 3.2 kgs |
@ Assembled to order
Eccentric Collar ball bearings
SLX Light duty 2-bolt flange bearings
| Series | Size | Part number | Description | Weight |
| 203 | 1/2 | 128151 | F2B-SL-008 | 0.45 lbs |
| 203 | 5/8 | 128154 | F2B-SL-010 | 0.42 lbs |
| 203 | 17 mm | 086789 | F2B-SL-17M | 0.20 kgs |
| 204 | 3/4 | 128092 | F2B-SL-012 | 0.55 lbs |
| 204 | 20 mm | 074287 | F2B-SL-20M | 0.25 kgs |
| 205 | 7/8 | 128174 | F2B-SL-014 | 0.891 lbs |
| 205 | 15/16 | 128175 | F2B-SL-015 | 0.77 lbs |
| 205 | 1 | 128093 | F2B-SL-010 | 0.65 lbs |
| 205 | 25 mm | 074288 | F2B-SL-25M | 0.34 kgs |
| 206 | 1-1/8 | 128176 | F2B-SL-016 | 1.05 lbs |
| 206 | 1-3/16 | 128094 | F2B-SL-010 | 1.02 lbs |
| 206 | 1-1/4 | 128097 | F2B-SL-010 | 1.00 lbs |
| 206 | 30 mm | @ | F2B-SL-30M | 0.46 kgs |
| 207 | 1-1/4 | 128095 | F2B-SL-015 | 1.53 lbs |
| 207 | 1-3/8 | 128177 | F2B-SL-010 | 1.50 lbs |
| 207 | 1-7/16 | 128096 | F2B-SL-010 | 1.37 lbs |
| 207 | 35 mm | 068532 | F2B-SL-35M | 0.67 kgs |
@ Assembled to order
Set screw ball bearings
SC Normal duty 2-bolt piloted flange bearings
| Series | Size | Part number | Description | Weight |
| 204 | 1/2 | @ | F2BZ-SC-008L | 1.2 lbs |
| 204 | 5/8 | 064775 | F2BZ-SC-010L | 1.2 lbs |
| 204 | 3/4 | 062648 | F2BZ-SC-012 | 1.1 lbs |
| 204 | 20 mm | 130367 | F2BZ-SC-20M | 0.3 kgs |
| 205 | 7/8 | 068915 | F2BZ-SC-014 | 1.4 lbs |
| 205 | 15/16 | @ | F2BZ-SC-015 | 1.4 lbs |
| 205 | 1 | 056929 | F2BZ-SC-100 | 1.4 lbs |
| 205 | 25 mm | 0130368 | F2BZ-SC-25M | 0.6 kgs |
| 206 | 1-1/8 | 049926 | F2BZ-SC-102 | 1.8 lbs |
| 206 | 1-3/16 | 064480 | F2BZ-SC-103 | 1.8 lbs |
| 206 | 1-1/4 | 064361 | F2BZ-SC-104S | 1.8 lbs |
| 206 | 30 mm | 130369 | F2BZ-SC-30M | 0.8 kgs |
| 207 | 1-1/4 | 064089 | F2BZ-SC-104 | 2.7 lbs |
| 207 | 1-3/8 | 068937 | F2BZ-SC-106 | 2.6 lbs |
| 207 | 1-7/16 | 065565 | F2BZ-SC-107 | 2.6 lbs |
| 207 | 35 mm | 130370 | F2BZ-SC-35M | 1.2 kgs |
| 208 | 1-1/2 | 062686 | F2BZ-SC-108 | 3.9 lbs |
| 208 | 1-5/8 | @ | F2BZ-SC-110 | 3.8 lbs |
| 208 | 40 mm | 130371 | F2BZ-SC-40M | 1.7 kgs |
| 209 | 1-5/8 | @ | F2BZ-SC-110L | 4.2 lbs |
| 209 | 1-11/16 | 68839 | F2BZ-SC-111 | 4.1 lbs |
| 209 | 1-3/4 | @ | F2BZ-SC-112 | 4.1 lbs |
| 209 | 45 mm | 130372 | F2BZ-SC-45M | 2.5 kgs |
| 210 | 1-15/16 | 056845 | F2BZ-SC-115 | 3.6 lbs |
| 210 | 2 | 074396 | F2BZ-SC-200 | 4.4 lbs |
| 210 | 50 mm | 130373 | F2BZ-SC-50M | 2.6 kgs |
@ Assembled to order
Set screw ball bearings
SL Light duty 3-bolt flange bearings
| Series | Size | Part number | Description | Weight |
| 204 | 3/4 | 128083 | F3B-SL-012 | 0.74 lbs |
| 204 | 20 mm | @ | F3B-SL-20M | 0.33 kgs |
| 205 | 7/8 | 128178 | F3B-SL-014 | 1.01 lbs |
| 205 | 15/16 | 128179 | F3B-SL-015 | 0.97 lbs |
| 205 | 1 | 128084 | F3B-SL-100 | 0.85 lbs |
| 205 | 25 mm | @ | F3B-SL-25M | 0.43 kgs |
| 206 | 1-1/8 | 128180 | F3B-SL-102 | 1.39 lbs |
| 206 | 1-3/16 | 128085 | F3B-SL-103 | 1.36 lbs |
| 206 | 1-1/4 | 128083 | F3B-SL-104S | 1.34 lbs |
| 206 | 30 mm | @ | F3B-SL-30M | 0.64 kgs |
| 207 | 1-1/4 | 128086 | F3B-SL-104 | 1.89 lbs |
| 207 | 1-3/8 | 128181 | F3B-SL-106 | 1.86 lbs |
| 207 | 1-7/16 | 128087 | F3B-SL-107 | 1.73 lbs |
| 207 | 35 mm | @ | F3B-SL-35M | 0.83 kgs |
@ Assembled to order
Set screw ball bearings
SC Normal duty 4-bolt flange bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 203 | 1/2 | 124048 | F4B-SC-008 | @ | F4B-SC-008-NL | 1.1 lbs |
| 203 | 5/8 | 124049 | F4B-SC-010 | 67642 | F4B-SC-010-NL | 1.0 lbs |
| 203 | 17 mm | 125885 | F4B-SC-17M | @ | F4B-SC-17M-NL | 0.5 kgs |
| 204 | 1/2 | 124098 | F4B-SC-008L | @ | F4B-SC-008L-NL | 1.8 lbs |
| 204 | 5/8 | 124099 | F4B-SC-010L | @ | F4B-SC-010L-NL | 1.7 lbs |
| 204 | 3/4 | 124100 | F4B-SC-012 | 52010 | F4B-SC-012-NL | 1.6 lbs |
| 204 | 13/16 | 124567 | F4B-SC-013 | @ | F4B-SC-013-NL | 1.5 lbs |
| 204 | 20 mm | 125886 | F4B-SC-20M | 74714 | F4B-SC-20M-NL | 0.8 kgs |
| 205 | 7/8 | 124101 | F4B-SC-014 | 75765 | F4B-SC-014-NL | 2.0 lbs |
| 205 | 15/16 | 124102 | F4B-SC-015 | 126524 | F4B-SC-015-NL | 1.9 lbs |
| 205 | 1 | 124103 | F4B-SC-100 | 126525 | F4B-SC-100-NL | 1.8 lbs |
| 205 | 25 mm | 125887 | F4B-SC-25M | 64943 | F4B-SC-25M-NL | 0.9 kgs |
| 206 | 1-1/16 | 124218 | F4B-SC-101 | @ | F4B-SC-101-NL | 2.9 lbs |
| 206 | 1-1/8 | 124204 | F4B-SC-102 | 126526 | F4B-SC-102-NL | 2.8 lbs |
| 206 | 1-3/16 | 124205 | F4B-SC-103 | 50834 | F4B-SC-103-NL | 2.7 lbs |
| 206 | 1-1/4 | 123173 | F4B-SC-104S | 51987 | F4B-SC-104S-NL | 2.6 lbs |
| 206 | 30 mm | 125888 | F4B-SC-30M | 67874 | F4B-SC-30M-NL | 1.3 kgs |
| 207 | 1-1/4 | 124206 | F4B-SC-104 | 126528 | F4B-SC-104-NL | 4.0 lbs |
| 207 | 1-5/16 | 124219 | F4B-SC-105 | @ | F4B-SC-105-NL | 3.9 lbs |
| 207 | 1-3/8 | 124207 | F4B-SC-106 | 52009 | F4B-SC-106-NL | 3.8 lbs |
| 207 | 1-7/16 | 124208 | F4B-SC-107 | 50835 | F4B-SC-107-NL | 3.7 lbs |
| 207 | 35 mm | 125889 | F4B-SC-35M | @ | F4B-SC-35M-NL | 1.7 kgs |
| 208 | 1-1/2 | 124209 | F4B-SC-108 | 51991 | F4B-SC-108-NL | 4.8 lbs |
| 208 | 1-5/8 | 124210 | F4B-SC-110 | 52008 | F4B-SC-110-NL | 4.7 lbs |
| 208 | 40 mm | 125890 | F4B-SC-40M | 73769 | F4B-SC-40M-NL | 2.1 kgs |
| 209 | 1-5/8 | 125170 | F4B-SC-110L | @ | F4B-SC-110L-NL | 6.1 lbs |
| 209 | 1-11/16 | 124211 | F4B-SC-111 | 64214 | F4B-SC-111-NL | 6.0 lbs |
| 209 | 1-3/4 | 124212 | F4B-SC-112 | 126531 | F4B-SC-112-NL | 5.9 lbs |
| 209 | 45 mm | 125891 | F4B-SC-45M | @ | F4B-SC-45M-NL | 2.7 kgs |
| 210 | 1-15/16 | 124213 | F4B-SC-115 | 51992 | F4B-SC-115-NL | 6.7 lbs |
| 210 | 2 | 124214 | F4B-SC-200 | 50867 | F4B-SC-200-NL | 6.6 lbs |
| 210 | 50 mm | 125892 | F4B-SC-50M | 68571 | F4B-SC-50M-NL | 3.0 kgs |
| 211 | 2 | 126192 | F4B-SCM-200 | 52004 | F4B-SCM-200-NL | 9.3 lbs |
| 211 | 2-3/16 | 124215 | F4B-SC-203 | 52007 | F4B-SC-203-NL | 9.0 lbs |
| 211 | 2-1/4 | 124216 | F4B-SC-204 | 52006 | F4B-SC-204-NL | 8.9 lbs |
| 211 | 55 mm | 125893 | F4B-SC-55M | 68572 | F4B-SC-55M-NL | 4.1 kgs |
| 212 | 2-1/4 | 126283 | F4B-SCM-204 | 126537 | F4B-SCM-204-NL | 11.1 lbs |
| 212 | 2-7/16 | 124217 | F4B-SC-207 | 50843 | F4B-SC-207-NL | 10.6 lbs |
| 212 | 60 mm | 125894 | F4B-SC-60M | 64203 | F4B-SC-60M-NL | 6.0 kgs |
| 214 | 2-1/2 | 126195 | F4B-SCM-208 | @ | F4B-SCM-208-NL | 16.0 lbs |
| 214 | 2-11/16 | 124261 | F4B-SC-211 | @ | F4B-SC-211-NL | 15.4 lbs |
| 214 | 70 mm | 125895 | F4B-SC-70M | @ | F4B-SC-70M-NL | 6.9 kgs |
| 215 | 2-15/16 | 124220 | F4B-SC-215 | 52291 | F4B-SC-215-NL | 17.6 lbs |
| 215 | 75 mm | 125896 | F4B-SC-75M | 68573 | F4B-SC-75M-NL | 8.0 kgs |
@ Assembled to order
Set screw ball bearings
SCM Medium duty 4-bolt flange bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 206 | 1 | 126226 | F4B-SCM-100 | 52017 | F4B-SCM-100-NL | 3.0 lbs |
| 206 | 25 mm | 125965 | F4B-SCM-25M | @ | F4B-SCM-25M-NL | 1.3 kgs |
| 207 | 1-3/16 | 126227 | F4B-SCM-103 | 56907 | F4B-SCM-103-NL | 4.1 lbs |
| 207 | 1-1/4 | 124206 | F4B-SC-104 | 126528 | F4B-SC-104-NL | 4.0 lbs |
| 207 | 30 mm | 125966 | F4B-SCM-30M | @ | F4B-SCM-30M-NL | 1.4 kgs |
| 208 | 1-7/16 | 126187 | F4B-SCM-107 | 62842 | F4B-SCM-107-NL | 5.0 lbs |
| 208 | 35 mm | 125967 | F4B-SCM-35M | @ | F4B-SCM-35M-NL | 2.1 kgs |
| 209 | 1-1/2 | 126188 | F4B-SCM-108 | 62897 | F4B-SCM-108-NL | 6.1 lbs |
| 209 | 1-5/8 | 125170 | F4B-SC-110L | @ | F4B-SC-110L-NL | 6.1 lbs |
| 209 | 40 mm | 125968 | F4B-SCM-40M | @ | F4B-SCM-40M-NL | 2.7 kgs |
| 210 | 1-11/16 | 126189 | F4B-SCM-111 | 65576 | F4B-SCM-111-NL | 7.1 lbs |
| 210 | 1-3/4 | 126190 | F4B-SCM-112 | @ | F4B-SCM-112-NL | 6.9 lbs |
| 210 | 45 mm | 125969 | F4B-SCM-45M | @ | F4B-SCM-45M-NL | 3.0 kgs |
| 211 | 1-15/16 | 126191 | F4B-SCM-115 | 52302 | F4B-SCM-115-NL | 9.5 lbs |
| 211 | 2 | 126192 | F4B-SCM-200 | 52004 | F4B-SCM-200-NL | 9.3 lbs |
| 211 | 50 mm | 125970 | F4B-SCM-50M | 73950 | F4B-SCM-50M-NL | 4.1 kgs |
| 212 | 2-3/16 | 126193 | F4B-SCM-203 | 52003 | F4B-SCM-203-NL | 11.3 lbs |
| 212 | 2-1/4 | 126283 | F4B-SCM-204 | 126537 | F4B-SCM-204-NL | 11.1 lbs |
| 212 | 55 mm | 125971 | F4B-SCM-55M | @ | F4B-SCM-55M-NL | 6.0 kgs |
| 214 | 2-7/16 | 126194 | F4B-SCM-207 | 52002 | F4B-SCM-207-NL | 16.2 lbs |
| 214 | 2-1/2 | 126195 | F4B-SCM-208 | 65653 | F4B-SCM-208-NL | 16.0 lbs |
| 214 | 65 mm | 125972 | F4B-SCM-65M | @ | F4B-SCM-65M-NL | 7.3 lbs |
| 215 | 2-11/16 | 126186 | F4B-SCM-211 | 52205 | F4B-SCM-211-NL | 18.3 lbs |
| 215 | 70 mm | 125973 | F4B-SCM-70M | @ | F4B-SCM-70M-NL | 8.0 kgs |
| 216 | 2-15/16 | 126196 | F4B-SCM-215 | 126538 | F4B-SCM-215-NL | 21.5 lbs |
| 216 | 3 | 126197 | F4B-SCM-300 | 126539 | F4B-SCM-300-NL | 21.2 lbs |
| 216 | 75 mm | 125974 | F4B-SCM-75M | @ | F4B-SCM-75M-NL | 9.4 kgs |
| 218 | 3-7/16 | 126198 | F4B-SCM-307 | 126540 | F4B-SCM-307-NL | 28.0 lbs |
| 218 | 3-1/2 | 126199 | F4B-SCM-308 | 126541 | F4B-SCM-308-NL | 27.4 lbs |
| 218 | 85 mm | 125975 | F4B-SCM-85M | @ | F4B-SCM-85M-NL | 12.2 kgs |
@ Assembled to order
Set screw ball bearings
SL Light duty 4-bolt flange bearings
| Series | Size | Part number | Description | Weight |
| 208 | 1-1/2 | 128088 | F4B-SL-108 | 2.64 lbs |
| 208 | 40 mm | 67868 | F4B-SL-40M | 1.15 kgs |
| 210 | 1-15/16 | 128089 | F4B-SL-115 | 2.95 lbs |
| 210 | 2 | 128090 | F4B-SL-200 | 2.86 lbs |
| 210 | 50 mm | @ | F4B-SL-50M | 1.28 kgs |
| 211 | 2 | 128182 | F4B-SL-200L | 3.73 lbs |
| 211 | 2-3/16 | 128091 | F4B-SL-203 | 3.63 lbs |
| 211 | 55 mm | @ | F4B-SL-55M | 1.62 kgs |
@ Assembled to order
Set screw ball bearings
SC FB Normal duty 3-bolt flanged bracket bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 204 | 1/2 | 124435 | FB-SC-008 | 68720 | FB-SC-008-NL | 1.51 lbs |
| 204 | 5/8 | 124436 | FB-SC-010 | 59816 | FB-SC-010-NL | 1.48 lbs |
| 204 | 3/4 | 124437 | FB-SC-012 | 58544 | FB-SC-012-NL | 1.45 lbs |
| 205 | 7/8 | 124438 | FB-SC-014 | 56765 | FB-SC-014-NL | 1.81 lbs |
| 205 | 15/16 | 124439 | FB-SC-015 | @ | FB-SC-015-NL | 1.78 lbs |
| 205 | 1 | 124440 | FB-SC-100 | 51774 | FB-SC-100-NL | 1.75 lbs |
| 206 | 1-1/16 | 124441 | FB-SC-101 | @ | FB-SC-101-NL | 2.12 lbs |
| 206 | 1-1/8 | 124442 | FB-SC-102 | @ | FB-SC-102-NL | 2.08 lbs |
| 206 | 1-3/16 | 124443 | FB-SC-103 | 49615 | FB-SC-103-NL | 2.05 lbs |
| 206 | 1-1/4 | 124444 | FB-SC-104S | 124450 | FB-SC-104S-NL | 2.02 lbs |
| 207 | 1-1/4 | 124445 | FB-SC-104 | 58545 | FB-SC-104-NL | 3.46 lbs |
| 207 | 1-5/16 | 124446 | FB-SC-105 | @ | FB-SC-105-NL | 3.41 lbs |
| 207 | 1-3/8 | 124447 | FB-SC-106 | @ | FB-SC-106-NL | 3.36 lbs |
| 207 | 1-7/16 | 124448 | FB-SC-107 | 52016 | FB-SC-107-NL | 3.3 lbs |
| 210 | 1-11/16 | 52906 | FB-SCM-111 | 68840 | FB-SCM-111-NL | 5.7 lbs |
| 210 | 1-15/16 | 52094 | FB-SC-115 | 73669 | FB-SC-115-NL | 5.5 lbs |
| 210 | 2 | 58529 | FB-SC-200 | 73139 | FB-SC-200-NL | 5.4 lbs |
@ Assembled to order
Set screw ball bearings
SC Normal duty piloted flange bearings
| Series | Size | Part number | Description | Weight |
| 206 | 1-1/16 | 124578 | FC-SC-101 | 3.2 lbs |
| 206 | 1-1/8 | 124582 | FC-SC-102 | 3.1 lbs |
| 206 | 1-3/16 | 124579 | FC-SC-103 | 3.0 lbs |
| 206 | 1-1/4 | 124587 | FC-SC-104S | 2.9 lbs |
| 206 | 30 mm | 125865 | FC-SC-30M | 1.3 lbs |
| 207 | 1-1/4 | 124224 | FC-SC-104 | 4.2 lbs |
| 207 | 1-5/16 | 124237 | FC-SC-105 | 4.1 lbs |
| 207 | 1-3/8 | 124235 | FC-SC-106 | 4.0 lbs |
| 207 | 1-7/16 | 124236 | FC-SC-107 | 3.9 lbs |
| 207 | 35 mm | 125866 | FC-SC-35M | 1.8 lbs |
| 208 | 1-1/2 | 124225 | FC-SC-108 | 4.6 lbs |
| 208 | 1-5/8 | 124226 | FC-SC-110 | 4.5 lbs |
| 208 | 40 mm | 125867 | FC-SC-40M | 2.0 lbs |
| 209 | 209 | 65644 | FC-SC-110L | 5.6 lbs |
| 209 | 209 | 124227 | FC-SC-111 | 5.5 lbs |
| 209 | 209 | 124228 | FC-SC-112 | 5.4 lbs |
| 209 | 209 | 125868 | FC-SC-45M | 2.4 lbs |
| 210 | 1-15/16 | 124229 | FC-SC-115 | 6.4 lbs |
| 210 | 2 | 124230 | FC-SC-200 | 6.3 lbs |
| 210 | 50 mm | 125869 | FC-SC-50M | 2.9 lbs |
| 211 | 2 | 126175 | FC-SCM-200 | 7.3 lbs |
| 211 | 2-3/16 | 124231 | FC-SC-203 | 7.2 lbs |
| 211 | 2-1/4 | 124232 | FC-SC-204 | 7.1 lbs |
| 211 | 55 mm | 125870 | FC-SC-55M | 3.3 lbs |
| 212 | 2-1/4 | 126177 | FC-SCM-204 | 9.6 lbs |
| 212 | 2-7/16 | 124233 | FC-SC-207 | 9.5 lbs |
| 212 | 60 mm | 125871 | FC-SC-60M | 4.3 lbs |
| 214 | 2-1/2 | 126179 | FC-SCM-208 | 13.0 lbs |
| 214 | 2-11/16 | 124729 | FC-SC-211 | 12.9 lbs |
| 214 | 70 mm | 125872 | FC-SC-70M | 5.5 lbs |
Set screw ball bearings
SC LFT Normal Duty 2-bolt flange bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 203 | 1/2 | 124640 | LFT-SC-008 | 124660 | LFT-SC-008-NL | 0.60 lbs |
| 203 | 5/8 | 124641 | LFT-SC-010 | 124661 | LFT-SC-010-NL | 0.55 lbs |
| 203 | 17 mm | 130362 | LFT-SC-17M | 124662 | LFT-SC-17M-NL | 0.27 kgs |
| 204 | 3/4 | 124642 | LFT-SC-012 | 124662 | LFT-SC-012-NL | 0.80 lbs |
| 204 | 20 mm | 130363 | LFT-SC-20M | 062260 | LFT-SC-20M-NL | 0.36 kgs |
| 205 | 7/8 | 124643 | LFT-SC-014 | 124663 | LFT-SC-014-NL | 0.95 lbs |
| 205 | 15/16 | 124644 | LFT-SC-015 | 124664 | LFT-SC-015-NL | 0.90 lbs |
| 205 | 1 | 124645 | LFT-SC-100 | 124665 | LFT-SC-100-NL | 0.85 lbs |
| 205 | 25 mm | 130364 | LFT-SC-25M | 068996 | LFT-SC-25M-NL | 0.43 kgs |
| 206 | 1-1/16 | 124646 | LFT-SC-101 | 124666 | LFT-SC-101-NL | 1.5 lbs |
| 206 | 1-1/8 | 124647 | LFT-SC-102 | 124667 | LFT-SC-102-NL | 1.45 lbs |
| 206 | 1-3/16 | 124648 | LFT-SC-103 | 124668 | LFT-SC-103-NL | 1.40 lbs |
| 206 | 1-1/4 | 124649 | LFT-SC-104S | 124669 | LFT-SC-104S-NL | 1.35 lbs |
| 206 | 30 mm | 130365 | LFT-SC-30M | @ | LFT-SC-30M-NL | 0.67 kgs |
| 207 | 1-1/4 | 124650 | LFT-SC-104 | 124670 | LFT-SC-104-NL | 1.85 lbs |
| 207 | 1-5/16 | 124651 | LFT-SC-105 | 124671 | LFT-SC-105-NL | 1.80 lbs |
| 207 | 1-3/8 | 124652 | LFT-SC-106 | 124672 | LFT-SC-106-NL | 1.75 lbs |
| 207 | 1-7/16 | 124653 | LFT-SC-107 | 124673 | LFT-SC-107-NL | 1.70 lbs |
| 207 | 35 mm | 130366 | LFT-SC-35M | @ | LFT-SC-35M-NL | 0.81 kgs |
@ Assembled to order
Set screw ball bearings
SC Normal duty wide slot take-up bearings
| Standard | Never lube/sealed for life (-NL) | |||||
| Series | Size | Part number | Description | Part number | Description | Weight |
| 204 | 1/2 | 125343 | WSTU-SC-008 | @ | WSTU-SC-008-NL | 2.1 lbs |
| 204 | 5/8 | 125344 | WSTU-SC-010 | @ | WSTU-SC-010-NL | 2.0 lbs |
| 204 | 3/4 | 125010 | WSTU-SC-012 | 74935 | WSTU-SC-012-NL | 1.9 lbs |
| 204 | 20 mm | 125910 | WSTU-SC-20M | @ | WSTU-SC-20M-NL | 0.9 kgs |
| 205 | 7/8 | 125356 | WSTU-SC-014 | @ | WSTU-SC-014-NL | 2.2 lbs |
| 205 | 15/16 | 125011 | WSTU-SC-015 | @ | WSTU-SC-015-NL | 2.1 lbs |
| 205 | 1 | 125012 | WSTU-SC-100 | @ | WSTU-SC-100-NL | 2.0 lbs |
| 205 | 25 mm | 125911 | WSTU-SC-25M | @ | WSTU-SC-25M-NL | 1.0 kgs |
| 206 | 1-1/16 | 125357 | WSTU-SC-101 | @ | WSTU-SC-101-NL | 3.1 lbs |
| 206 | 1-1/8 | 125358 | WSTU-SC-102 | @ | WSTU-SC-102-NL | 3.0 lbs |
| 206 | 1-3/16 | 125113 | WSTU-SC-103 | @ | WSTU-SC-103-NL | 2.9 lbs |
| 206 | 1-1/4 | 123175 | WSTU-SC-104S | @ | WSTU-SC-104S-NL | 2.8 lbs |
| 206 | 30 mm | 125912 | WSTU-SC-30M | @ | WSTU-SC-30M-NL | 1.3 kgs |
| 207 | 1-1/4 | 125360 | WSTU-SC-104 | 73793 | WSTU-SC-104-NL | 3.8 lbs |
| 207 | 1-5/16 | 125359 | WSTU-SC-105 | @ | WSTU-SC-105-NL | 3.7 lbs |
| 207 | 1-3/8 | 125361 | WSTU-SC-106 | @ | WSTU-SC-106-NL | 3.6 lbs |
| 207 | 1-7/16 | 125114 | WSTU-SC-107 | 50846 | WSTU-SC-107-NL | 3.5 lbs |
| 207 | 35 mm | 125913 | WSTU-SC-35M | @ | WSTU-SC-35M-NL | 1.6 kgs |
| 208 | 1-1/2 | 125120 | WSTU-SC-108 | 49829 | WSTU-SC-108-NL | 6.1 lbs |
| 208 | 1-5/8 | 125355 | WSTU-SC-110 | @ | WSTU-SC-110-NL | 6.0 lbs |
| 208 | 40 mm | 125914 | WSTU-SC-40M | @ | WSTU-SC-40M-NL | 2.8 kgs |
| 209 | 1-5/8 | 125151 | WSTU-SC-110L | @ | WSTU-SC-110L-NL | 6.1 lbs |
| 209 | 1-11/16 | 125115 | WSTU-SC-111 | @ | WSTU-SC-111-NL | 6.0 lbs |
| 209 | 1-3/4 | 125362 | WSTU-SC-112 | @ | WSTU-SC-112-NL | 5.9 lbs |
| 209 | 1-13/16 | 125121 | WSTU-SC-113 | @ | WSTU-SC-113-NL | 5.8 lbs |
| 209 | 45 mm | 125915 | WSTU-SC-45M | @ | WSTU-SC-45M-NL | 2.7 kgs |
| 210 | 1-15/16 | 125116 | WSTU-SC-115 | 125071 | WSTU-SC-115-NL | 6.4 lbs |
| 210 | 2 | 125363 | WSTU-SC-200 | 62691 | WSTU-SC-200-NL | 6.2 lbs |
| 210 | 50 mm | 125916 | WSTU-SC-50M | 68374 | WSTU-SC-50M-NL | 2.9 kgs |
| 211 | 2 | 135183 | WSTU-SCM-200 | 58705 | WSTU-SCM-200-NL | 10.1 lbs |
| 211 | 2-3/16 | 125117 | WSTU-SC-203 | @ | WSTU-SC-203-NL | 10.0 lbs |
| 211 | 2-1/4 | 125364 | WSTU-SC-204 | @ | WSTU-SC-204-NL | 9.8 lbs |
| 211 | 55 mm | 125917 | WSTU-SC-55M | @ | WSTU-SC-55M-NL | 4.5 kgs |
| 212 | 2-1/4 | 135184 | WSTU-SCM-204 | @ | WSTU-SCM-204-NL | 11.2 lbs |
| 212 | 2-7/16 | 125118 | WSTU-SC-207 | @ | WSTU-SC-207-NL | 10.8 lbs |
| 212 | 60 mm | 125918 | WSTU-SC-60M | @ | WSTU-SC-60M-NL | 4.9 kgs |
| 214 | 2-1/2 | 135185 | WSTU-SCM-208 | @ | WSTU-SCM-208-NL | 18.0 lbs |
| 214 | 2-11/16 | 64704 | WSTU-SC-211 | @ | WSTU-SC-211-NL | 17.8 lbs |
| 214 | 70 mm | 62975 | WSTU-SC-70M | @ | WSTU-SC-70M-NL | 8.0 kgs |
| 215 | 2-15/16 | 125119 | WSTU-SC-215 | @ | WSTU-SC-215-NL | 18.9 lbs |
| 215 | 75 mm | 125919 | WSTU-SC-75M | @ | WSTU-SC-75M-NL | 8.6 kgs |
@ Assembled to order
Set screw ball bearings
SCM Medium duty narrow slot take-up bearings
| Series | Size | Part number | Description | Weight |
| 206 | 1 | 135102 | NSTU-SCM-100 | 3.0 lbs |
| 206 | 25 mm | 125980 | NSTU-SCM-25M | 1.2 kgs |
| 207 | 1-3/16 | 135081 | NSTU-SCM-103 | 2.9 lbs |
| 207 | 1-1/4 | 125154 | NSTU-SC-104 | 2.8 lbs |
| 207 | 30 mm | 125981 | NSTU-SCM-30M | 1.3 kgs |
| 208 | 1-7/16 | 135105 | NSTU-SCM-107 | 4.7 lbs |
| 208 | 35 mm | 125982 | NSTU-SCM-35M | 2.2 kgs |
| 209 | 1-1/2 | 135106 | NSTU-SCM-108 | 5.0 lbs |
| 209 | 1-5/8 | 65593 | NSTU-SC-110L | 4.9 lbs |
| 209 | 40 mm | 125983 | NSTU-SCM-40M | 2.3 kgs |
| 210 | 1-11/16 | 135107 | NSTU-SCM-111 | 5.3 lbs |
| 210 | 1-3/4 | 135170 | NSTU-SCM-112 | 5.2 lbs |
| 210 | 45 mm | 125984 | NSTU-SCM-45M | 2.4 kgs |
| 211 | 1-15/16 | 135109 | NSTU-SCM-115 | 7.0 lbs |
| 211 | 2 | 135171 | NSTU-SCM-200 | 6.8 lbs |
| 211 | 50 mm | 125985 | NSTU-SCM-50M | 3.2 kgs |
| 212 | 2-3/16 | 135111 | NSTU-SCM-203 | 8.9 lbs |
| 212 | 2-1/4 | 135172 | NSTU-SCM-204 | 8.7 lbs |
| 212 | 55 mm | 125986 | NSTU-SCM-55M | 4.0 kgs |
Set screw ball bearings
Type G&GM Medium duty top angle take-up bearings
| Series | Size | Part number | Description | Weight |
| 210 | 1-15/16 | 012340 | TP-G-115 | 10.2 lbs |
| 210 | 2 | 012302 | TP-G-200 | 10.0 lbs |
| 211 | 2 | 136081 | TP-GM-200 | 12.5 lbs |
| 211 | 2-3/16 | 012341 | TP-G-203 | 12.4 lbs |
| 211 | 2-1/4 | 012303 | TP-G-204 | 1.02 lbs |
| 212 | 2-1/4 | 136082 | TP-GM-204 | 16.0 lbs |
| 212 | 2-7/16 | 012342 | TP-G-207 | 15.9 lbs |
| 214 | 2-1/2 | 136083 | TP-GM-208 | 21.3 lbs |
| 214 | 2-11/15 | @ | TP-G-211 | 21.1 lbs |
| 215 | 2-15/16 | 012343 | TP-G-215 | 21.2 lbs |
| 210 | 1-11/16 | 136070 | TP-GM-111 | 10.4 lbs |
| 210 | 1-3/16 | 136080 | TP-GM-112 | 10.0 lbs |
| 211 | 1-15/16 | 136071 | TP-GM-115 | 12.8 lbs |
| 211 | 2 | 138081 | TP-GM-200 | 12.5 lbs |
| 212 | 2-3/16 | 136072 | TP-GM-203 | 16.2 lbs |
| 212 | 2-1/4 | 136082 | TP-GM-204 | 16.0 lbs |
| 214 | 2-7/16 | 136073 | TP-GM-207 | 21.7 lbs |
| 214 | 2-1/2 | 036083 | TP-GM-208 | 21.0 lbs |
| 215 | 2-11/16 | 136076 | TP-GM-211 | 25.0 lbs |
| 216 | 2-15/16 | 136074 | TP-GM-215 | 29.8 lbs |
| 216 | 3 | 136084 | TP-GM-300 | 29.5 lbs |
| 218 | 3-7/16 | 136075 | TP-GM-307 | 40.2 lbs |
| 218 | 3-1/2 | 136085 | TP-GM-308 | 40.0 lbs |
@ Assembled to order
Set screw ball bearings
SC Normal duty screw conveyor hanger bearings
| Series | Size | Part number | Description | Weight |
| 206 | 1 | 57878 | SCHB-SC-100 | 3.0 lbs |
| 206 | 1-1/8 | 73287 | SCHB-SC-102 | 3.0 lbs |
| 207 | 1-3/16 | 57220 | SCHB-SC-103 | 3.5 lbs |
| 207 | 1-1/4 | 124996 | SCHB-SC-104 | 3.5 lbs |
| 207 | 1-3/8 | 58630 | SCHB-SC-106 | 3.5 lbs |
| 208 | 1-7/16 | 126049 | SCHB-SC-107 | 3.4 lbs |
| 208 | 1-1/2 | 124290 | SCHB-SC-108 | 3.4 lbs |
| 208 | 1-5/8 | 124404 | SCHB-SC-110 | 3.8 lbs |
| 210 | 1-11/16 | 124408 | SCHB-SC-111 | 5.4 lbs |
| 210 | 1-3/4 | 124299 | SCHB-SC-112 | 4.8 lbs |
| 210 | 1-15/16 | 124405 | SCHB-SC-115 | 4.5 lbs |
| 210 | 2 | 124291 | SCHB-SC-200 | 4.4 lbs |
| 212 | 2-3/16 | 124409 | SCHB-SC-203 | 5.0 lbs |
| 212 | 2-1/4 | 124419 | SCHB-SC-204 | 5.0 lbs |
| 212 | 2-7/16 | 124292 | SCHB-SC-207 | 7.4 lbs |
| 216 | 2-15/16 | 124406 | SCHB-SC-215 | 14.0 lbs |
| 216 | 3 | 124293 | SCHB-SC-300 | 14.6 lbs |
| 218 | 3-7/16 | 053320 | SCHB-SCM-307 | 21.2 lbs |
| 218 | 3-1/2 | 057361 | SCHB-SCM-308 | 21.0 lbs |
Set screw ball bearings
SC Normal duty hanger bearings
| Series | Size | Part number | Description | Weight |
| 206 | 1-1/16 | 124420 | HNG-SC-101 | 2.0 lbs |
| 206 | 1-1/8 | 124421 | HNG-SC-102 | 1.9 lbs |
| 206 | 1-3/16 | 124240 | HNG-SC-103 | 1.8 lbs |
| 206 | 1-1/4 | 123176 | HNG-SC-104S | 1.7 lbs |
| 207 | 1-1/4 | 124422 | HNG-SC-104 | 2.8 lbs |
| 207 | 1-5/16 | 124423 | HNG-SC-105 | 2.6 lbs |
| 207 | 1-3/8 | 124424 | HNG-SC-106 | 2.4 lbs |
| 207 | 1-7/16 | 124242 | HNG-SC-107 | 2.2 lbs |
| 210 | 1-15/16 | 124245 | HNG-SC-115 | 6.2 lbs |
| 210 | 2 | 124393 | HNG-SC-200 | 6.0 lbs |
