Mounted Spherical Roller Bearings Dodge

Bấm để xem catalogue và bản vẽ

Danh mục: ,
Chiết khấu giảm giá

Mô tả

Gối Đỡ Vòng Bi Tang Trống (Mounted Spherical Roller Bearings)

Trong hơn 100 năm, các nhà sản xuất hàng đầu trong nhiều lĩnh vực công nghiệp đã tin dùng gối đỡ vòng bi tang trống của Dodge để đáp ứng yêu cầu về hệ thống băng tải và truyền động công suất. Uy tín về độ bền, độ tin cậy và chất lượng vận hành của sản phẩm được duy trì qua nhiều thế hệ, đồng thời thúc đẩy sự phát triển của một danh mục vòng bi hoàn chỉnh dựa trên nền tảng kỹ thuật và cải tiến liên tục.

Hiện nay, gối đỡ vòng bi tang trống Dodge mang đến các thiết kế tiên tiến, hiệu suất ổn định, chất lượng đồng nhất, nhiều tùy chọn phương pháp cố định trục, cùng các sản phẩm sáng chế độc quyền như Safety Mount®, giúp nâng cao giá trị sử dụng và tối ưu hóa vận hành trong các ứng dụng công nghiệp.

Vui lòng tham khảo chi tiết trong catalog.

Tìm hiểu thêm về:

  • Dòng Safety Mount®

  • S-2000

  • USAF

  • Unisphere II

#DodgeBearing #MountedBearings #TaperedRollerBearings #BallBearings #DodgeIndustrial #MechanicalPowerTransmission #IndustrialBearings #BearingSolutions #TypeEBearing
#EXLBearing #TAFBearing #DoubleInterlock #SpecialDutyBearing #HingedCapBearing #TypeKBearing #TypeCBearing #DodgeBallBearing #PillowBlockHousing #FlangeBearing #MountedBallBearings #SphericalRollerBearings #MountedSphericalBearings #DodgeSphericalBearing

Bearing Engineering Catalog: Bấm để xem

IMPERIAL – IP Pillow Block – Inch
1-1/8 THRU 4 INCH – 2-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22208 1-1/8 069400 P2B-IP-102R 069428 P2B-IP-102RE 069456 P2B-IP-102L 069484 P2B-IP-102LE
22208 1-3/16 069401 P2B-IP-103R 069429 P2B-IP-103RE 069457 P2B-IP-103L 069485 P2B-IP-103LE
22208 1-1/4 069402 P2B-IP-104R 069430 P2B-IP-104RE 069458 P2B-IP-104L 069486 P2B-IP-104LE
22208 1-3/8 069403 P2B-IP-106R 069431 P2B-IP-106RE 069459 P2B-IP-106L 069487 P2B-IP-106LE
22208 1-7/16 069404 P2B-IP-107R 069432 P2B-IP-107RE 069460 P2B-IP-107L 069488 P2B-IP-107LE
22208 1-1/2 069405 P2B-IP-108R 069433 P2B-IP-108RE 069461 P2B-IP-108L 069489 P2B-IP-108LE
22209 1-5/8 069406 P2B-IP-110R 069434 P2B-IP-110RE 069462 P2B-IP-110L 069490 P2B-IP-110LE
22209 1-11/16 069407 P2B-IP-111R 069435 P2B-IP-111RE 069463 P2B-IP-111L 069491 P2B-IP-111LE
22209 1-3/4 069408 P2B-IP-112R 069436 P2B-IP-112RE 069464 P2B-IP-112L 069492 P2B-IP-112LE
22210 1-7/8 069409 P2B-IP-114R 069437 P2B-IP-114RE 069465 P2B-IP-114L 069493 P2B-IP-114LE
22210 1-15/16 069410 P2B-IP-115R 069438 P2B-IP-115RE 069466 P2B-IP-115L 069494 P2B-IP-115LE
22210 2 069411 P2B-IP-200R 069439 P2B-IP-200RE 069467 P2B-IP-200L 069495 P2B-IP-200LE
22211 2-3/16 069412 P2B-IP-203R 069440 P2B-IP-203RE 069468 P2B-IP-203L 069496 P2B-IP-203LE
22211 2-1/4 069413 P2B-IP-204R 069441 P2B-IP-204RE 069469 P2B-IP-204L 069497 P2B-IP-204LE
22213 2-3/8 069414 P2B-IP-206R 069442 P2B-IP-206RE 069470 P2B-IP-206L 069498 P2B-IP-206LE
22213 2-7/16 069415 P2B-IP-207R 069443 P2B-IP-207RE 069471 P2B-IP-207L 069499 P2B-IP-207LE
22213 2-1/2 069416 P2B-IP-208R 069444 P2B-IP-208RE 069472 P2B-IP-208L 069500 P2B-IP-208LE
22215 2-11/16 069417 P2B-IP-211R 069445 P2B-IP-211RE 069473 P2B-IP-211L 069501 P2B-IP-211LE
22215 2-3/4 069418 P2B-IP-212R 069446 P2B-IP-212RE 069474 P2B-IP-212L 069502 P2B-IP-212LE
22215 2-15/16 069419 P2B-IP-215R 069447 P2B-IP-215RE 069475 P2B-IP-215L 069503 P2B-IP-215LE
22215 3 069420 P2B-IP-300R 069448 P2B-IP-300RE 069476 P2B-IP-300L 069504 P2B-IP-300LE
22218 3-3/16 069421 P2B-IP-303R 069449 P2B-IP-303RE 069477 P2B-IP-303L 069505 P2B-IP-303LE
22218 3-1/4 069422 P2B-IP-304R 069450 P2B-IP-304RE 069478 P2B-IP-304L 069506 P2B-IP-304LE
22218 3-7/16 069423 P2B-IP-307R 069451 P2B-IP-307RE 069479 P2B-IP-307L 069507 P2B-IP-307LE
22218 3-1/2 069424 P2B-IP-308R 069452 P2B-IP-308RE 069480 P2B-IP-308L 069508 P2B-IP-308LE
22220 3-11/16 069425 P2B-IP-311R 069453 P2B-IP-311RE 069481 P2B-IP-311L 069509 P2B-IP-311LE
22220 3-15/16 069426 P2B-IP-315R 069454 P2B-IP-315RE 069482 P2B-IP-315L 069510 P2B-IP-315LE
22220 4 069427 P2B-IP-400R 069455 P2B-IP-400RE 069483 P2B-IP-400L 069511 P2B-IP-400LE

IMPERIAL – IP Pillow Block with Type E Dimensions
1-3/8 THRU 2-3/16 INCH 2-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22208 1-3/8 071120 EP2B-IP-106R 071141 EP2B-IP-106RE 071162 EP2B-IP-106L 071183 EP2B-IP-106LE
22208 1-7/16 071121 EP2B-IP-107R 071142 EP2B-IP-107RE 071163 EP2B-IP-107L 071184 EP2B-IP-107LE
22209 1-1/2 071122 EP2B-IP-108R 071143 EP2B-IP-108RE 071164 EP2B-IP-108L 071185 EP2B-IP-108LE
22209 1-5/8 071123 EP2B-IP-110R 071144 EP2B-IP-110RE 071165 EP2B-IP-110L 071186 EP2B-IP-110LE
22209 1-11/16 071124 EP2B-IP-111R 071145 EP2B-IP-111RE 071166 EP2B-IP-111L 071187 EP2B-IP-111LE
22210 1-3/4 071125 EP2B-IP-112R 071146 EP2B-IP-112RE 071167 EP2B-IP-112L 071188 EP2B-IP-112LE
22210 1-7/8 071126 EP2B-IP-114R 071147 EP2B-IP-114RE 071168 EP2B-IP-114L 071189 EP2B-IP-114LE
22210 1-15/16 071127 EP2B-IP-115R 071148 EP2B-IP-115RE 071169 EP2B-IP-115L 071190 EP2B-IP-115LE
22210 2 071128 EP2B-IP-200R 071149 EP2B-IP-200RE 071170 EP2B-IP-200L 071191 EP2B-IP-200LE
22211 2-3/16 071129 EP2B-IP-203R 071150 EP2B-IP-203RE 071171 EP2B-IP-203L 071192 EP2B-IP-203LE
22213 2-1/4 071130 EP2B-IP-204R 071151 EP2B-IP-204RE 071172 EP2B-IP-204L 071193 EP2B-IP-204LE
22213 2-7/16 071131 EP2B-IP-207R 071152 EP2B-IP-207RE 071173 EP2B-IP-207L 071194 EP2B-IP-207LE
22213 2-1/2 071132 EP2B-IP-208R 071153 EP2B-IP-208RE 071174 EP2B-IP-208L 071195 EP2B-IP-208LE
22215 2-11/16 071133 EP2B-IP-211R 071154 EP2B-IP-211RE 071175 EP2B-IP-211L 071196 EP2B-IP-211LE
22215 2-3/4 071134 EP2B-IP-212R 071155 EP2B-IP-212RE 071176 EP2B-IP-212L 071197 EP2B-IP-212LE
22215 2-15/16 071135 EP2B-IP-215R 071156 EP2B-IP-215RE 071177 EP2B-IP-215L 071198 EP2B-IP-215LE
22215 3 071136 EP2B-IP-300R 071157 EP2B-IP-300RE 071178 EP2B-IP-300L 071199 EP2B-IP-300LE
22218 3-3/16 071137 EP2B-IP-303R 071158 EP2B-IP-303RE 071179 EP2B-IP-303L 071200 EP2B-IP-303LE
22218 3-1/4 071138 EP2B-IP-304R 071159 EP2B-IP-304RE 071180 EP2B-IP-304L 071201 EP2B-IP-304LE
22218 3-7/16 071139 EP2B-IP-307R 071160 EP2B-IP-307RE 071181 EP2B-IP-307L 071202 EP2B-IP-307LE
22218 3-1/2 071140 EP2B-IP-308R 071161 EP2B-IP-308RE 071182 EP2B-IP-308L 071203 EP2B-IP-308LE
22208 1-3/8 071120 EP2B-IP-106R 071141 EP2B-IP-106RE 071162 EP2B-IP-106L 071183 EP2B-IP-106LE
22208 1-7/16 071121 EP2B-IP-107R 071142 EP2B-IP-107RE 071163 EP2B-IP-107L 071184 EP2B-IP-107LE
22209 1-1/2 071122 EP2B-IP-108R 071143 EP2B-IP-108RE 071164 EP2B-IP-108L 071185 EP2B-IP-108LE
22209 1-5/8 071123 EP2B-IP-110R 071144 EP2B-IP-110RE 071165 EP2B-IP-110L 071186 EP2B-IP-110LE
22209 1-11/16 071124 EP2B-IP-111R 071145 EP2B-IP-111RE 071166 EP2B-IP-111L 071187 EP2B-IP-111LE
22210 1-3/4 071125 EP2B-IP-112R 071146 EP2B-IP-112RE 071167 EP2B-IP-112L 071188 EP2B-IP-112LE
22210 1-7/8 071126 EP2B-IP-114R 071147 EP2B-IP-114RE 071168 EP2B-IP-114L 071189 EP2B-IP-114LE
22210 1-15/16 071127 EP2B-IP-115R 071148 EP2B-IP-115RE 071169 EP2B-IP-115L 071190 EP2B-IP-115LE
22210 2 071128 EP2B-IP-200R 071149 EP2B-IP-200RE 071170 EP2B-IP-200L 071191 EP2B-IP-200LE
22211 2-3/16 071129 EP2B-IP-203R 071150 EP2B-IP-203RE 071171 EP2B-IP-203L 071192 EP2B-IP-203LE
22213 2-1/4 071130 EP2B-IP-204R 071151 EP2B-IP-204RE 071172 EP2B-IP-204L 071193 EP2B-IP-204LE
22213 2-7/16 071131 EP2B-IP-207R 071152 EP2B-IP-207RE 071173 EP2B-IP-207L 071194 EP2B-IP-207LE
22213 2-1/2 071132 EP2B-IP-208R 071153 EP2B-IP-208RE 071174 EP2B-IP-208L 071195 EP2B-IP-208LE
22215 2-11/16 071133 EP2B-IP-211R 071154 EP2B-IP-211RE 071175 EP2B-IP-211L 071196 EP2B-IP-211LE
22215 2-3/4 071134 EP2B-IP-212R 071155 EP2B-IP-212RE 071176 EP2B-IP-212L 071197 EP2B-IP-212LE
22215 2-15/16 071135 EP2B-IP-215R 071156 EP2B-IP-215RE 071177 EP2B-IP-215L 071198 EP2B-IP-215LE
22215 3 071136 EP2B-IP-300R 071157 EP2B-IP-300RE 071178 EP2B-IP-300L 071199 EP2B-IP-300LE
22218 3-3/16 071137 EP2B-IP-303R 071158 EP2B-IP-303RE 071179 EP2B-IP-303L 071200 EP2B-IP-303LE
22218 3-1/4 071138 EP2B-IP-304R 071159 EP2B-IP-304RE 071180 EP2B-IP-304L 071201 EP2B-IP-304LE
22218 3-7/16 071139 EP2B-IP-307R 071160 EP2B-IP-307RE 071181 EP2B-IP-307L 071202 EP2B-IP-307LE
22218 3-1/2 071140 EP2B-IP-308R 071161 EP2B-IP-308RE 071182 EP2B-IP-308L 071203 EP2B-IP-308LE

Steel IMPERIAL-HD Pillow Block 2-Bolt

Shaft Size Non-Expansion Expansion
Part No. Description Part No. Description
1-1/8 071650 SP2B-IP-102R 071678 SP2B-IP-102RE
1-3/16 071651 SP2B-IP-103R 071679 SP2B-IP-103RE
1-1/4 071652 SP2B-IP-104R 071680 SP2B-IP-104RE
1-3/8 071653 SP2B-IP-106R 071681 SP2B-IP-106RE
1-7/16 071654 SP2B-IP-107R 071682 SP2B-IP-107RE
1-1/2 071655 SP2B-IP-108R 071683 SP2B-IP-108RE
1-5/8 071656 SP2B-IP-110R 071684 SP2B-IP-110RE
1-11/16 071657 SP2B-IP-111R 071685 SP2B-IP-111RE
1-3/4 071658 SP2B-IP-112R 071686 SP2B-IP-112RE
1-7/8 071659 SP2B-IP-114R 071687 SP2B-IP-114RE
1-15/16 071660 SP2B-IP-115R 071688 SP2B-IP-115RE
2 071661 SP2B-IP-200R 071689 SP2B-IP-200RE
2-3/16 071662 SP2B-IP-203R 071690 SP2B-IP-203RE
2-1/4 071663 SP2B-IP-204R 071691 SP2B-IP-204RE
2-3/8 071664 SP2B-IP-206R 071692 SP2B-IP-206RE
2-7/16 071665 SP2B-IP-207R 071693 SP2B-IP-207RE
2-1/2 071666 SP2B-IP-208R 071694 SP2B-IP-208RE
2-11/16 071667 SP2B-IP-211R 071695 SP2B-IP-211RE
2-3/4 071668 SP2B-IP-212R 071696 SP2B-IP-212RE
2-15/16 071669 SP2B-IP-215R 071697 SP2B-IP-215RE
3 071670 SP2B-IP-300R 071698 SP2B-IP-300RE
3-3/16 071671 SP2B-IP-303R 071699 SP2B-IP-303RE
3-1/4 071672 SP2B-IP-304R 071700 SP2B-IP-304RE
3-7/16 071673 SP2B-IP-307R 071701 SP2B-IP-307RE
3-1/2 071674 SP2B-IP-308R 071702 SP2B-IP-308RE
3-11/16 071675 SP2B-IP-311R 071703 SP2B-IP-311RE
3-15/16 071676 SP2B-IP-315R 071704 SP2B-IP-315RE

Steel IMPERIAL-HD Pillow Block 2-Bolt with Type E Dimensions

Shaft Size Non-Expansion Expansion
Part No. Description Part No. Description
1-3/8 071864 SEP2B-IP-106R 071885 SEP2B-IP-106RE
1-7/16 071865 SEP2B-IP-107R 071886 SEP2B-IP-107RE
1-1/2 071866 SEP2B-IP-108R 071887 SEP2B-IP-108RE
1-5/8 071867 SEP2B-IP-110R 071888 SEP2B-IP-110RE
1-11/16 071868 SEP2B-IP-111R 071889 SEP2B-IP-111RE
1-3/4 071869 SEP2B-IP-112R 071890 SEP2B-IP-112RE
1-7/8 071870 SEP2B-IP-114R 071891 SEP2B-IP-114RE
1-15/16 071871 SEP2B-IP-115R 071892 SEP2B-IP-115RE
2 071872 SEP2B-IP-200R 071893 SEP2B-IP-200RE
2-3/16 071873 SEP2B-IP-203R 071894 SEP2B-IP-203RE
2-1/4 071874 SEP2B-IP-204R 071895 SEP2B-IP-204RE
2-7/16 071875 SEP2B-IP-207R 071896 SEP2B-IP-207RE
2-1/2 071876 SEP2B-IP-208R 071897 SEP2B-IP-208RE
2-11/16 071877 SEP2B-IP-211R 071898 SEP2B-IP-211RE
2-3/4 071878 SEP2B-IP-212R 071899 SEP2B-IP-212RE
2-15/16 071879 SEP2B-IP-215R 071900 SEP2B-IP-215RE
3 071880 SEP2B-IP-300R 071901 SEP2B-IP-300RE
3-3/16 071881 SEP2B-IP-303R 071902 SEP2B-IP-303RE
3-1/4 071882 SEP2B-IP-304R 071903 SEP2B-IP-304RE
3-7/16 071883 SEP2B-IP-307R 071904 SEP2B-IP-307RE
3-1/2 071884 SEP2B-IP-308R 071905 SEP2B-IP-308RE

IMPERIAL – IP Pillow Block
2-3/8 THRU 5 INCH – 4-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22213 2-3/8 069520 P4B-IP-206R 069538 P4B-IP-206RE 069556 P4B-IP-206L 069574 P4B-IP-206LE
22213 2-7/16 069521 P4B-IP-207R 069539 P4B-IP-207RE 069557 P4B-IP-207L 069575 P4B-IP-207LE
22213 2-1/2 069522 P4B-IP-208R 069540 P4B-IP-208RE 069558 P4B-IP-208L 069576 P4B-IP-208LE
22215 2-11/16 069523 P4B-IP-211R 069541 P4B-IP-211RE 069559 P4B-IP-211L 069577 P4B-IP-211LE
22215 2-3/4 069524 P4B-IP-212R 069542 P4B-IP-212RE 069560 P4B-IP-212L 069578 P4B-IP-212LE
22215 2-15/16 069525 P4B-IP-215R 069543 P4B-IP-215RE 069561 P4B-IP-215L 069579 P4B-IP-215LE
22215 3 069526 P4B-IP-300R 069544 P4B-IP-300RE 069562 P4B-IP-300L 069580 P4B-IP-300LE
22218 3-3/16 069527 P4B-IP-303R 069545 P4B-IP-303RE 069563 P4B-IP-303L 069581 P4B-IP-303LE
22218 3-1/4 069528 P4B-IP-304R 069546 P4B-IP-304RE 069564 P4B-IP-304L 069582 P4B-IP-304LE
22218 3-7/16 069529 P4B-IP-307R 069547 P4B-IP-307RE 069565 P4B-IP-307L 069583 P4B-IP-307LE
22218 3-1/2 069530 P4B-IP-308R 069548 P4B-IP-308RE 069566 P4B-IP-308L 069584 P4B-IP-308LE
22220 3-11/16 069531 P4B-IP-311R 069549 P4B-IP-311RE 069567 P4B-IP-311L 069585 P4B-IP-311LE
22220 3-15/16 069532 P4B-IP-315R 069550 P4B-IP-315RE 069568 P4B-IP-315L 069586 P4B-IP-315LE
22220 4 069533 P4B-IP-400R 069551 P4B-IP-400RE 069569 P4B-IP-400L 069587 P4B-IP-400LE
22222 4-7/16 069534 P4B-IP-407R 069552 P4B-IP-407RE 069570 P4B-IP-407L 069588 P4B-IP-407LE
22222 4-1/2 069535 P4B-IP-408R 069553 P4B-IP-408RE 069571 P4B-IP-408L 069589 P4B-IP-408LE
22226 4-15/16 069536 P4B-IP-415R 069554 P4B-IP-415RE 069572 P4B-IP-415L 069590 P4B-IP-415LE
22226 5 069537 P4B-IP-500R 069555 P4B-IP-500RE 069573 P4B-IP-500L 069591 P4B-IP-500LE

Steel IMPERIAL-HD Pillow Block 4-Bolt

Shaft Size Non-Expansion Expansion
Part No. Description Part No. Description
2-3/8 071706 SP4B-IP-206R 071724 SP4B-IP-206RE
2-7/16 071707 SP4B-IP-207R 071725 SP4B-IP-207RE
2-1/2 071708 SP4B-IP-208R 071726 SP4B-IP-208RE
2-11/16 071709 SP4B-IP-211R 071727 SP4B-IP-211RE
2-3/4 071710 SP4B-IP-212R 071728 SP4B-IP-212RE
2-15/16 071711 SP4B-IP-215R 071729 SP4B-IP-215RE
3 071712 SP4B-IP-300R 071730 SP4B-IP-300RE
3-3/16 071713 SP4B-IP-303R 071731 SP4B-IP-303RE
3-1/4 071714 SP4B-IP-304R 071732 SP4B-IP-304RE
3-7/16 071715 SP4B-IP-307R 071733 SP4B-IP-307RE
3-1/2 071716 SP4B-IP-308R 071734 SP4B-IP-308RE
3-11/16 071717 SP4B-IP-311R 071735 SP4B-IP-311RE
3-15/16 071718 SP4B-IP-315R 071736 SP4B-IP-315RE
4 071719 SP4B-IP-400R 071737 SP4B-IP-400RE
4-7/16 071720 SP4B-IP-407R 071738 SP4B-IP-407RE
4-1/2 071721 SP4B-IP-408R 071739 SP4B-IP-408RE
4-15/16 071722 SP4B-IP-415R 071740 SP4B-IP-415RE
5 071723 SP4B-IP-500R 071741 SP4B-IP-500RE

Steel IMPERIAL-HD Pillow Block 4-Bolt with Type E Dimensions

Shaft Size Non-Expansion Expansion
Part No. Description Part No. Description
2-1/4 071906 SEP4B-IP-204R 071923 SEP4B-IP-204RE
2-7/16 071907 SEP4B-IP-207R 071924 SEP4B-IP-207RE
2-1/2 071908 SEP4B-IP-208R 071925 SEP4B-IP-208RE
2-11/16 071909 SEP4B-IP-211R 071926 SEP4B-IP-211RE
2-3/4 071910 SEP4B-IP-212R 071927 SEP4B-IP-212RE
2-15/16 071911 SEP4B-IP-215R 071928 SEP4B-IP-215RE
3 071912 SEP4B-IP-300R 071929 SEP4B-IP-300RE
3-3/16 071913 SEP4B-IP-303R 071930 SEP4B-IP-303RE
3-1/4 071914 SEP4B-IP-304R 071931 SEP4B-IP-304RE
3-7/16 071915 SEP4B-IP-307R 071932 SEP4B-IP-307RE
3-1/2 071916 SEP4B-IP-308R 071933 SEP4B-IP-308RE
3-15/16 071917 SEP4B-IP-315R 071934 SEP4B-IP-315RE
4 071918 SEP4B-IP-400R 071935 SEP4B-IP-400RE
4-7/16 071919 SEP4B-IP-407R 071936 SEP4B-IP-407RE
4-1/2 071920 SEP4B-IP-408R 071937 SEP4B-IP-408RE
4-15/16 071921 SEP4B-IP-415R 071938 SEP4B-IP-415RE
5 071922 SEP4B-IP-500R 071939 SEP4B-IP-500RE



IMPERIAL ISAF
1-7/16 THRU 3-7/16 INCH – 2-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22208 1-7/16 070054 P2B509-ISAF-107R 070064 P2B509-ISAF-107RE 070074 P2B509-ISAF-107L 070084 P2B509-ISAF-107LE
22209 1-11/16 070055 P2B510-ISAF-111R 070065 P2B510-ISAF-111RE 070075 P2B510-ISAF-111L 070085 P2B510-ISAF-111LE
22210 1-15/16 070056 P2B511-ISAF-115R 070066 P2B511-ISAF-115RE 070076 P2B511-ISAF-115L 070086 P2B511-ISAF-115LE
22211 2-3/16 070057 P2B513-ISAF-203R 070067 P2B513-ISAF-203RE 070077 P2B513-ISAF-203L 070087 P2B513-ISAF-203LE
22213 2-7/16 070951 P2B515-ISAF-207R 070955 P2B515-ISAF-207RE 070959 P2B515-ISAF-207L 070963 P2B515-ISAF-207LE
22215 2-11/16 070952 P2B516-ISAF-211R 070956 P2B516-ISAF-211RE 070960 P2B516-ISAF-211L 070964 P2B516-ISAF-211LE
22215 2-15/16 070953 P2B517-ISAF-215R 070957 P2B517-ISAF-215RE 070961 P2B517-ISAF-215L 070965 P2B517-ISAF-215LE
22218 3-7/16 070954 P2B520-ISAF-307R 070958 P2B520-ISAF-307RE 070962 P2B520-ISAF-307L 070966 P2B520-ISAF-307LE

IMPERIAL ISAF
2-7/16 THRU 7 INCH – 4-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22213 2-7/16 070058 P4B515-ISAF-207R 070068 P4B515-ISAF-207RE 070078 P4B515-ISAF-207L 070088 P4B515-ISAF-207LE
22215 2-11/16 070094 P4B516-ISAF-211R 070095 P4B516-ISAF-211RE 070096 P4B516-ISAF-211L 070097 P4B516-ISAF-211LE
22215 2-15/16 070059 P4B517-ISAF-215R 070069 P4B517-ISAF-215RE 070079 P4B517-ISAF-215L 070089 P4B517-ISAF-215LE
22218 3-7/16 070060 P4B520-ISAF-307R 070070 P4B520-ISAF-307RE 070080 P4B520-ISAF-307L 070090 P4B520-ISAF-307LE
22220 3-15/16 070061 P4B522-ISAF-315R 070071 P4B522-ISAF-315RE 070081 P4B522-ISAF-315L 070091 P4B522-ISAF-315LE
22222 4-7/16 070062 P4B526-ISAF-407R 070072 P4B526-ISAF-407RE 070082 P4B526-ISAF-407L 070092 P4B526-ISAF-407LE
22226 4-15/16 070063 P4B528-ISAF-415R 070073 P4B528-ISAF-415RE 070083 P4B528-ISAF-415L 070093 P4B528-ISAF-415LE
22228 5-7/16 037850 P4B532-ISAF-507R 037854 P4B532-ISAF-507RE 037901 P4B532-ISAF-507L 037902 P4B532-ISAF-507LE
22228 5-1/2 037903 P4B532-ISAF-508R 037904 P4B532-ISAF-508RE 037905 P4B532-ISAF-508L 037906 P4B532-ISAF-508LE
22232 5-15/16 037851 P4B534-ISAF-515R 037855 P4B534-ISAF-515RE 037907 P4B534-ISAF-515L 037908 P4B534-ISAF-515LE
22232 6 037909 P4B534-ISAF-600R 037910 P4B534-ISAF-600RE 037911 P4B534-ISAF-600L 037912 P4B534-ISAF-600LE
22236 6-7/16 037852 P4B536-ISAF-607R 037856 P4B536-ISAF-607RE 037913 P4B536-ISAF-607L 037914 P4B536-ISAF-607LE
22236 6-1/2 037915 P4B536-ISAF-608R 037916 P4B536-ISAF-608RE 037917 P4B536-ISAF-608L 037918 P4B536-ISAF-608LE
22236 6-15/16 037853 P4B538-ISAF-615R 037857 P4B538-ISAF-615RE 037919 P4B538-ISAF-615L 037920 P4B538-ISAF-615LE
22236 7 037921 P4B538-ISAF-700R 037922 P4B538-ISAF-700RE 037923 P4B538-ISAF-700L 037924 P4B538-ISAF-700LE

IMPERIAL ISAF
65 THRU 170MM – 4-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22215 65 077660 P4B515-ISAF-065MR P4B515-ISAF-065MRE P4B515-ISAF-065ML P4B515-ISAF-065MLE
22215 70 077661 P4B516-ISAF-070MR P4B516-ISAF-070MRE P4B516-ISAF-070ML P4B516-ISAF-070MLE
22215 75 062700 P4B517-ISAF-075MR P4B517-ISAF-075MRE P4B517-ISAF-075ML P4B517-ISAF-075MLE
22218 85 077458 P4B520-ISAF-085MR P4B520-ISAF-085MRE P4B520-ISAF-085ML P4B520-ISAF-085MLE
22220 90 077662 P4B520-ISAF-090MR P4B520-ISAF-090MRE P4B520-ISAF-090ML P4B520-ISAF-090MLE
22220 90 073070 P4B522-ISAF-090MR 073071 P4B522-ISAF-090MRE P4B522-ISAF-090ML P4B522-ISAF-090MLE
22220 100 074867 P4B522-ISAF-100MR 074868 P4B522-ISAF-100MRE P4B522-ISAF-100ML P4B522-ISAF-100MLE
22222 110 075444 P4B526-ISAF-110MR 077561 P4B526-ISAF-110MRE P4B526-ISAF-110ML P4B526-ISAF-110MLE
22226 115 077652 P4B526-ISAF-115MR P4B526-ISAF-115MRE P4B526-ISAF-115ML P4B526-ISAF-115MLE
22226 125 075431 P4B528-ISAF-125MR P4B528-ISAF-125MRE 077473 P4B528-ISAF-125ML P4B528-ISAF-125MLE
22228 130 075306 P4B532-ISAF-130MR P4B532-ISAF-130MRE P4B532-ISAF-130ML P4B532-ISAF-130MLE
22228 140 073938 P4B532-ISAF-140MR P4B532-ISAF-140MRE P4B532-ISAF-140ML P4B532-ISAF-140MLE
22232 150 075432 P4B534-ISAF-150MR 077897 P4B534-ISAF-150MRE P4B534-ISAF-150ML P4B534-ISAF-150MLE
22236 160 074613 P4B536-ISAF-160MR 074614 P4B536-ISAF-160MRE P4B536-ISAF-160ML P4B536-ISAF-160MLE
22236 170 062461 P4B536-ISAF-170MR P4B536-ISAF-170MRE P4B536-ISAF-170ML P4B536-ISAF-170MLE
22236 170 062270 P4B538-ISAF-170MR P4B538-ISAF-170MRE P4B538-ISAF-170ML P4B538-ISAF-170MLE

IMPERIAL ISAF
35 THRU 90MM – 2-BOLT

Bearing Shaft Size Trident Seal Labyrinth Seal
Non-Expansion Expansion Non-Expansion Expansion
Part No. Part Name Part No. Part Name Part No. Part Name Part No. Part Name
22208 35 068774 P2B509-ISAF-035MR 068775 P2B509-ISAF-035MRE P2B509-ISAF-035ML P2B509-ISAF-035MLE
22209 40 077646 P2B509-ISAF-040MR P2B509-ISAF-040MRE P2B509-ISAF-040ML P2B509-ISAF-040MLE
22210 45 077647 P2B510-ISAF-045MR P2B510-ISAF-045MRE P2B510-ISAF-045ML P2B510-ISAF-045MLE
22210 50 073562 P2B511-ISAF-050MR 073561 P2B511-ISAF-050MRE P2B511-ISAF-050ML P2B511-ISAF-050MLE
22213 60 077648 P2B513-ISAF-060MR P2B513-ISAF-060MRE 067921 P2B515-ISAF-060ML 067922 P2B515-ISAF-060MLE
22213 60 068576 P2B515-ISAF-060MR P2B515-ISAF-060MRE P2B515-ISAF-060ML P2B515-ISAF-060MLE
22215 65 077649 P2B515-ISAF-065MR P2B515-ISAF-065MRE P2B515-ISAF-065ML P2B515-ISAF-065MLE
22215 70 077650 P2B516-ISAF-070MR P2B516-ISAF-070MRE P2B516-ISAF-070ML P2B516-ISAF-070MLE
22215 65 065641 P2B517-ISAF-065MR P2B517-ISAF-065MRE P2B517-ISAF-065ML P2B517-ISAF-065MLE
22215 75 065657 P2B517-ISAF-075MR 068905 P2B517-ISAF-075MRE P2B517-ISAF-075ML P2B517-ISAF-075MLE
22220 90 077651 P2B520-ISAF-090MR P2B520-ISAF-090MRE P2B520-ISAF-090ML P2B520-ISAF-090MLE
