Mounted Tapered Roller Bearings Dodge

Bấm để xem catalogue và bản vẽ

Danh mục: ,
Chiết khấu giảm giá

Mô tả

Gối Đỡ Vòng Bi Côn (Mounted Tapered Roller Bearings)

Được tin dùng và chứng minh hiệu quả trong hơn 100 năm, các dòng gối đỡ vòng bi côn của chúng tôi có nhiều kiểu housing và cấu hình lắp đặt khác nhau để đáp ứng mọi nhu cầu ứng dụng. Dòng vòng bi Type E được xuất xưởng sẵn sàng tích hợp cảm biến OPTIFY™ giúp giám sát tình trạng từ xa một cách dễ dàng.

Với danh mục sản phẩm hoàn chỉnh về gối đỡ vòng bi côn, chúng tôi mang đến giải pháp vận hành đáng tin cậy cho mọi hệ thống, kể cả khi chịu tải hướng kính (radial) và tải dọc trục (thrust) ở mọi mức độ.

Hãy khám phá catalog để biết thêm chi tiết.

Tìm hiểu thêm về:

  • Type E
  • Type EXL
  • TAF
  • Double Interlock
  • Type K
  • Special Duty
  • Type C
  • Hinged Cap

#DodgeBearing #MountedBearings #TaperedRollerBearings #BallBearings #DodgeIndustrial #MechanicalPowerTransmission #IndustrialBearings #BearingSolutions #TypeEBearing
#EXLBearing #TAFBearing #DoubleInterlock #SpecialDutyBearing #HingedCapBearing #TypeKBearing #TypeCBearing #DodgeBallBearing #PillowBlockHousing #FlangeBearing #MountedBallBearings #SphericalRollerBearings #MountedSphericalBearings #DodgeSphericalBearing

Bearing Engineering Catalog: BẤM ĐỂ XEM

Type E pillow block – inch
2-bolt

Gray Iron Cast Steel
Size Part number Description Weight (lbs) Part number Description Weight (lbs)
1-3/16 023000 P2B-E-103R 4 023047 SP2B-E-103R 4
1-1/4 023001 P2B-E-104R 4 023048 SP2B-E-104R 4
1-3/8 023002 P2B-E-106R 7 023049 SP2B-E-106R 7
1-7/16 023003 P2B-E-107R 7 023050 SP2B-E-107R 7
1-1/2 023004 P2B-E-108R 10 023051 SP2B-E-108R 10
1-5/8 023005 P2B-E-110R 10 023052 SP2B-E-110R 10
1-11/16 023006 P2B-E-111R 10 023053 SP2B-E-111R 10
1-3/4 023007 P2B-E-112R 12 023054 SP2B-E-112R 11
1-7/8 023008 P2B-E-114R 12 023055 SP2B-E-114R 11
1-15/16 023009 P2B-E-115R 12 023056 SP2B-E-115R 11
2 023010 P2B-E-200R 12 023057 SP2B-E-200R 11
2-3/16 023011 P2B-E-203R 15 023058 SP2B-E-203R 14
2-1/4 023012 P2B-E-204R 21 023059 SP2B-E-204R 19
2-7/16 023013 P2B-E-207R 20 023060 SP2B-E-207R 19
2-1/2 023014 P2B-E-208R 20 023061 SP2B-E-208R 19
2-11/16 023015 P2B-E-211R 29 023062 SP2B-E-211R 26
2-3/4 023016 P2B-E-212R 28 023063 SP2B-E-212R 26
2-15/16 023017 P2B-E-215R 27 023064 SP2B-E-215R 26
3 023018 P2B-E-300R 27 023065 SP2B-E-300R 26
3-3/16 023019 P2B-E-303R 48 023066 SP2B-E-303R 44
3-1/4 023020 P2B-E-304R 47 023067 SP2B-E-304R 44
3-7/16 023021 P2B-E-307R 46 023068 SP2B-E-307R 44
3-1/8 023022 P2B-E-308R 45 023069 SP2B-E-308R 44

Type E pillow block – inch
4-bolt

Gray Iron Cast Steel
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
2-1/4 023023 P4B-E-204R 20 ——- ——- ——-
2-7/16 023024 P4B-E-207R 20 ——- ——- ——-
2-1/2 023025 P4B-E-208R 19 ——- ——- ——-
2-11/16 023026 P4B-E-211R 30 ——- ——- ——-
2-3/4 023027 P4B-E-212R 28 ——- ——- ——-
2-15/16 023028 P4B-E-215R 28 ——- ——- ——-
3 023029 P4B-E-300R 28 ——- ——- ——-
3-3/16 023030 P4B-E-303R 47 ——- ——- ——-
3-1/4 023031 P4B-E-304R 47 ——- ——- ——-
3-7/16 023032 P4B-E-307R 46 ——- ——- ——-
3-1/2 023033 P4B-E-308R 45 ——- ——- ——-
3-15/16 023690 P4B-E-315R 69 023070 SP4B-E-315R 65
4 023691 P4B-E-400R 69 023071 SP4B-E-400R 65
4-7/16 023692 P4B-E-407R 85 023072 SP4B-E-407R 81
4-1/2 023693 P4B-E-408R 85 023073 SP4B-E-408R 81
4-15/16 023694 P4B-E-415R 134 023074 SP4B-E-415R 132
5 023695 P4B-E-500R 133 023075 SP4B-E-500R 132
5-7/16 023040 P4B-E-507R 230 ——- ——- ——-
5-15/16 023041 P4B-E-515R 250 ——- ——- ——-
6 023042 P4B-E-600R 245 ——- ——- ——-
6-7/16 023043 P4B-E-607R 356 ——- ——- ——-
6-1/2 023044 P4B-E-608R 350 ——- ——- ——-
6-15/16 023045 P4B-E-615R 340 ——- ——- ——-
7 023046 P4B-E-700R 335 ——- ——- ——-

#Consult dodge for sizes not listed

Type EXL pillow block – inch
2-bolt

Size (inches) Non-Expansion Part No. Description Expansion Part No. Description Weight (lbs)
1-3/16 077221 P2B-EXL-103R 077244 P2B-EXL-103RE 10
1-1/4 077222 P2B-EXL-104R 077245 P2B-EXL-104RE 10
1-3/8 077223 P2B-EXL-106R 077246 P2B-EXL-106RE 12
1-7/16 077224 P2B-EXL-107R 077247 P2B-EXL-107RE 12
1-1/2 077225 P2B-EXL-108R 077248 P2B-EXL-108RE 12
1-5/8 077226 P2B-EXL-110R 077249 P2B-EXL-110RE 15
1-11/16 077227 P2B-EXL-111R 077250 P2B-EXL-111RE 15
1-3/4 077228 P2B-EXL-112R 077251 P2B-EXL-112RE 15
1-7/8 077229 P2B-EXL-114R 077252 P2B-EXL-114RE 19
1-15/16 077230 P2B-EXL-115R 077253 P2B-EXL-115RE 19
2 077231 P2B-EXL-200R 077254 P2B-EXL-200RE 19
2-3/16 077232 P2B-EXL-203R 077255 P2B-EXL-203RE 24
2-1/4 077233 P2B-EXL-204R 077256 P2B-EXL-204RE 24
2-7/16 077234 P2B-EXL-207R 077257 P2B-EXL-207RE 29
2-1/2 077235 P2B-EXL-208R 077258 P2B-EXL-208RE 29
2-11/16 077236 P2B-EXL-211R 077259 P2B-EXL-211RE 42
2-3/4 077237 P2B-EXL-212R 077260 P2B-EXL-212RE 42
2-15/16 077238 P2B-EXL-215R 077261 P2B-EXL-215RE 43
3 077239 P2B-EXL-300R 077262 P2B-EXL-300RE 43
3-3/16 077240 P2B-EXL-303R 077263 P2B-EXL-303RE 73
3-1/4 077241 P2B-EXL-304R 077264 P2B-EXL-304RE 73
3-7/16 077242 P2B-EXL-307R 077265 P2B-EXL-307RE 73
3-1/2 077243 P2B-EXL-308R 077266 P2B-EXL-308RE 73

Type EXL Pillow Block – Inch
4-bolt

Size (inches) Non-Expansion Part No. Description Expansion Part No. Description Weight (lbs)
2-1/4 077267 P4B-EXL-204R 077284 P4B-EXL-204RE 29
2-7/16 077268 P4B-EXL-207R 077285 P4B-EXL-207RE 29
2-1/2 077269 P4B-EXL-208R 077286 P4B-EXL-208RE 29
2-11/16 077270 P4B-EXL-211R 077287 P4B-EXL-211RE 42
2-3/4 077271 P4B-EXL-212R 077288 P4B-EXL-212RE 42
2-15/16 077272 P4B-EXL-215R 077289 P4B-EXL-215RE 42
3 077273 P4B-EXL-300R 077290 P4B-EXL-300RE 42
3-3/16 077274 P4B-EXL-303R 077291 P4B-EXL-303RE 73
3-1/4 077275 P4B-EXL-304R 077292 P4B-EXL-304RE 73
3-7/16 077276 P4B-EXL-307R 077293 P4B-EXL-307RE 73
3-1/2 077277 P4B-EXL-308R 077294 P4B-EXL-308RE 73
3-15/16 077278 P4B-EXL-315R 077295 P4B-EXL-315RE 109
4 077279 P4B-EXL-400R 077296 P4B-EXL-400RE 109
4-7/16 077280 P4B-EXL-407R 077297 P4B-EXL-407RE 154
4-1/2 077281 P4B-EXL-408R 077298 P4B-EXL-408RE 154
4-15/16 077282 P4B-EXL-415R 077299 P4B-EXL-415RE 192
5 077283 P4B-EXL-500R 077300 P4B-EXL-500RE 192

TAF Pillow block-inch
2-bolt

Standard – Non-expansion Standard – Expansion
Size (inches) Part number Description Part number Description Weight (lbs) Bearing inner unit
1-7/16 037580 P2B509-TAF-107R 037592 P2B509-TAF-107RE 12 037632
1-11/16 037581 P2B510-TAF-111R 037593 P2B510-TAF-111RE 15 037633
1-15/16 037582 P2B511-TAF-115R 037594 P2B511-TAF-115RE 17 037634
2-3/16 037583 P2B513-TAF-203R 037595 P2B513-TAF-203RE 25 037635
2-7/16 037584 P2B515-TAF-207R 037596 P2B515-TAF-207RE 30 037636
2-1/2 037585 P2B515-TAF-208R 037597 P2B515-TAF-208RE 30 037637
2-11/16 037586 P2B516-TAF-211R 037598 P2B516-TAF-211RE 38 037638
2-3/4 037587 P2B516-TAF-212R 037599 P2B516-TAF-212RE 38 037639
2-15/16 037588 P2B517-TAF-215R 037600 P2B517-TAF-215RE 45 037640
3 037589 P2B517-TAF-300R 037601 P2B517-TAF-300RE 44 037641
3-7/16 037590 P2B520-TAF-307R 037602 P2B520-TAF-307RE 71 037642
3-1/2 037591 P2B520-TAF-308R 037603 P2B520-TAF-308RE 70 037643

TAF Pillow Block – Inch
4-bolt

Gray Iron – Non-expansion Gray Iron – Expansion
Size (inches) Part number Description Part number Description Weight (lbs) Bearing inner unit
2-7/16 037604 P4B515-TAF-207R 037618 P4B515-TAF-207RE 30 037636
2-1/2 037605 P4B515-TAF-208R 037619 P4B515-TAF-208RE 30 037637
2-11/16 037606 P4B516-TAF-211R 037620 P4B516-TAF-211RE 38 037638
2-3/4 037607 P4B516-TAF-212R 037621 P4B516-TAF-212RE 38 037639
2-15/16 037608 P4B517-TAF-215R 037622 P4B517-TAF-215RE 45 037640
3 037609 P4B517-TAF-300R 037623 P4B517-TAF-300RE 44 037641
3-7/16 037610 P4B520-TAF-307R 037624 P4B520-TAF-307RE 71 037642
3-1/2 037611 P4B520-TAF-308R 037625 P4B520-TAF-308RE 70 037643
3-15/16 037612 P4B522-TAF-315R 037626 P4B522-TAF-315RE 110 037644
4 037613 P4B522-TAF-400R 037627 P4B522-TAF-400RE 110 037645
4-7/16 037614 P4B526-TAF-407R 037628 P4B526-TAF-407RE 140 037646
4-1/2 037615 P4B526-TAF-408R 037629 P4B526-TAF-408RE 140 037647
4-15/16 037616 P4B528-TAF-415R 037630 P4B528-TAF-415RE 180 037648
5 037617 P4B528-TAF-500R 037631 P4B528-TAF-500RE 180 037649
5-7/16 023584 P4B532-TAF-507R 23603 P4B532-TAF-507RE 300 023610
5-15/16 023585 P4B534-TAF-515R 23604 P4B534-TAF-515RE 300 023611
6 023586 P4B534-TAF-600R 23605 P4B534-TAF-600RE 300 023612
6-7/16 023587 P4B536-TAF-607R 23606 P4B536-TAF-607RE 510 023613
6-1/2 023588 P4B536-TAF-608R 23607 P4B536-TAF-608RE 510 023614
6-15/16 023589 P4B538-TAF-615R 23608 P4B538-TAF-615RE 476 023615
7 023590 P4B538-TAF-700R 23609 P4B538-TAF-700RE 468 023616

Double Interlock pillow block – inch
2-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs) Bearing inner units
1-1/4 023329 P2B-DI-104R 9 023376 P2B-DI-104RE 10 023508
1-3/8 023330 P2B-DI-106R 13 023377 P2B-DI-106RE 13 023509
1-7/16 023331 P2B-DI-107R 13 023378 P2B-DI-107RE 13 023510
1-1/2 023332 P2B-DI-108R 17 023379 P2B-DI-108RE 17 023511
1-5/8 023333 P2B-DI-110R 17 023380 P2B-DI-110RE 16 023512
1-11/16 023334 P2B-DI-111R 17 023381 P2B-DI-111RE 16 023513
1-3/4 023335 P2B-DI-112R 21 023382 P2B-DI-112RE 21 023514
1-15/16 023337 P2B-DI-115R 21 023384 P2B-DI-115RE 21 023516
2 023338 P2B-DI-200R 21 023385 P2B-DI-200RE 21 023517
2-3/16 023339 P2B-DI-203R 26 023386 P2B-DI-203RE 25 023518
2-1/4 023340 P2B-DI-204R 33 023387 P2B-DI-204RE 30 023519
2-7/16 023341 P2B-DI-207R 32 023388 P2B-DI-207RE 32 023520
2-1/2 023342 P2B-DI-208R 32 023389 P2B-DI-208RE 32 023521
2-11/16 023343 P2B-DI-211R 46 023390 P2B-DI-211RE 45 023522
2-3/4 023344 P2B-DI-212R 46 023391 P2B-DI-212RE 44 023523
2-15/16 023345 P2B-DI-215R 44 023392 P2B-DI-215RE 43 023524
3 023346 P2B-DI-300R 43 023393 P2B-DI-300RE 43 023525
3-3/16 023347 P2B-DI-303R 77 023394 P2B-DI-303RE 75 023526
3-7/16 023349 P2B-DI-307R 75 023396 P2B-DI-307RE 74 023528
3-1/2 023350 P2B-DI-308R 75 023397 P2B-DI-308RE 73 023529

Double Interlock pillow block – inch
4-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs) Bearing inner units
2-7/16 023352 P4B-DI-207R 33 023399 P4B-DI-207RE 32 023520
2-1/2 023353 P4B-DI-208R 32 023400 P4B-DI-208RE 32 023521
2-11/16 023354 P4B-DI-211R 47 023401 P4B-DI-211RE 46 023522
2-15/16 023356 P4B-DI-215R 46 023403 P4B-DI-215RE 45 023524
3 023357 P4B-DI-300R 45 023404 P4B-DI-300RE 45 023525
3-7/16 023360 P4B-DI-307R 79 023407 P4B-DI-307RE 72 023528
3-1/2 023361 P4B-DI-308R 78 023408 P4B-DI-308RE 77 023529
3-15/16 023362 P4B-DI-315R 118 023409 P4B-DI-315RE 116 023530
4 023363 P4B-DI-400R 118 023410 P4B-DI-400RE 118 023531
4-7/16 023364 P4B-DI-407R 154 023411 P4B-DI-407RE 152 023532
4-1/2 023365 P4B-DI-408R 135 023412 P4B-DI-408RE 150 023533
4-15/16 023366 P4B-DI-415R 200 023413 P4B-DI-415RE 198 023534
5 023367 P4B-DI-500R 200 023414 P4B-DI-500RE 197 023535
5-7/16 023368 P4B-DI-507R 329 023415 P4B-DI-507RE 311 023536
5-15/16 023369 P4B-DI-515R 314 023416 P4B-DI-515RE 302 023537

Type C pillow block – inch
2-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
1-3/16 065289 P2B-C-103 21 087262 P2B-C-103E 22
1-1/4 065311 P2B-C-104 20 087263 P2B-C-104E 22
1-7/16 065290 P2B-C-107 20 087180 P2B-C-107E 20
1-1/2 065312 P2B-C-108 28 087264 P2B-C-108E 28
1-11/16 065291 P2B-C-111 28 087181 P2B-C-111E 28
1-3/4 065238 P2B-C-112 26 087172 P2B-C-112E 28
1-15/16 065292 P2B-C-115 29 087182 P2B-C-115E 29
2 065313 P2B-C-200 47 087265 P2B-C-200E 49
2-3/16 065293 P2B-C-203 47 087183 P2B-C-203E 49
2-1/4 065314 P2B-C-204 47 087266 P2B-C-204E 49
2-7/16 065294 P2B-C-207 57 087184 P2B-C-207E 57
2-1/2 065315 P2B-C-208 83 087267 P2B-C-208E 90
2-11/16 065295 P2B-C-211 83 087185 P2B-C-211E 90
2-7/8 065244 P2B-C-214 83 087178 P2B-C-214E 90
2-15/16 065296 P2B-C-215 83 087186 P2B-C-215E 90
3 065316 P2B-C-300 132 087268 P2B-C-300E 135
3-3/16 065317 P2B-C-303 132 087269 P2B-C-303E 135
3-7/16 065297 P2B-C-307 128 087187 P2B-C-307E 131

Type C pillow block – inch
4-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
2-7/16 065310 P4B-C-207 59 087191 P4B-C-207E 59
2-15/16 065302 P4B-C-215 85 087192 P4B-C-215E 85
3-7/16 065303 P4B-C-307 130 087193 P4B-C-307E 135
3-15/16 065298 P4B-C-315 230 087188 P4B-C-315E 230
4-7/16 065299 P4B-C-407 280 087189 P4B-C-407E 290
4-15/16 065300 P4B-C-415 370 087190 P4B-C-415E 380

Special Duty pillow block – inch
2-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
1-3/8 066213 P2B-SD-106 20 066249 P2B-SD-106E 22
1-7/16 066214 P2B-SD-107 20 066250 P2B-SD-107E 22
1-1/2 066300 P2B-SD-108 20 066306 P2B-SD-108E 22
1-9/16 066212 P2B-SD-109 27 066248 P2B-SD-109E 28
1-5/8 066228 P2B-SD-110 27 066243 P2B-SD-110E 28
1-11/16 066216 P2B-SD-111 27 066252 P2B-SD-111E 28
1-3/4 066301 P2B-SD-112 27 066307 P2B-SD-112E 28
1-7/8 066217 P2B-SD-114 33 066253 P2B-SD-114E 33
1-15/16 066218 P2B-SD-115 32 066254 P2B-SD-115E 32
2 066302 P2B-SD-200 32 066308 P2B-SD-200E 32
2-1/8 066215 P2B-SD-202 48 066257 P2B-SD-202E 50
2-3/16 066220 P2B-SD-203 47 066256 P2B-SD-203E 49
2-1/4 066303 P2B-SD-204 47 066309 P2B-SD-204E 49
2-7/16 066222 P2B-SD-207 56 066258 P2B-SD-207E 60
2-1/2 066246 P2B-SD-208 56 066247 P2B-SD-208E 60
2-5/8 066223 P2B-SD-210 84 066262 P2B-SD-210E 80
2-11/16 066304 P2B-SD-211 84 066310 P2B-SD-211E 80
2-3/4 066226 P2B-SD-212 84 066263 P2B-SD-212E 80
2-15/16 066230 P2B-SD-215 82 066266 P2B-SD-215E 78
3 066305 P2B-SD-300 82 066311 P2B-SD-300E 78
3-3/16 066232 P2B-SD-303 120 066269 P2B-SD-303E 120
3-3/8 066237 P2B-SD-306 119 066271 P2B-SD-306E 119
3-7/16 066234 P2B-SD-307 118 066270 P2B-SD-307E 118
3-1/2 066236 P2B-SD-308 118 066273 P2B-SD-308E 118

Special Duty pillow block – inch
4-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
2-3/8 066360 P4B-SD-206 60 066400 P4B-SD-206E 60
2-7/16 066224 P4B-SD-207 60 066260 P4B-SD-207E 60
2-1/2 066244 P4B-SD-208 60 066245 P4B-SD-208E 60
2-11/16 066225 P4B-SD-211 82 066261 P4B-SD-211E 82
2-3/4 066363 P4B-SD-212 82 066403 P4B-SD-212E 82
2-7/8 066365 P4B-SD-214 81 066405 P4B-SD-214E 81
2-15/16 066231 P4B-SD-215 80 066268 P4B-SD-215E 80
3 066366 P4B-SD-300 80 066406 P4B-SD-300E 80
3-3/16 066367 P4B-SD-303 124 066407 P4B-SD-303E 124
3-3/8 066370 P4B-SD-306 122 066410 P4B-SD-306E 122
3-7/16 066235 P4B-SD-307 120 066272 P4B-SD-307E 120
3-1/2 066371 P4B-SD-308 120 066411 P4B-SD-308E 120
3-11/16 066372 P4B-SD-311 215 066412 P4B-SD-311E 230
3-3/4 066373 P4B-SD-312 215 066413 P4B-SD-312E 230
3-7/8 066374 P4B-SD-314 215 066414 P4B-SD-314E 230
3-15/16 066238 P4B-SD-315 215 066274 P4B-SD-315E 230
4 066375 P4B-SD-400 215 066415 P4B-SD-400E 230
4-7/16 066240 P4B-SD-407 296 066276 P4B-SD-407E 296
4-1/2 066377 P4B-SD-408 296 066417 P4B-SD-408E 296
4-15/16 066242 P4B-SD-415 380 066278 P4B-SD-415E 380
5 066378 P4B-SD-500 380 066418 P4B-SD-500E 380
5-7/16 066379 P4B-SD-507 585 066419 P4B-SD-507E 585
5-15/16 066381 P4B-SD-515 585 066421 P4B-SD-51SE 585
6 066382 P4B-SD-600 585 066422 P4B-SD-600E 585

Type K Pillow Block
2 & 4 Bolt Base – Inch

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Part number Description Weight (lbs)
1-3/16 023167 P2B-K-103R 023189 P2B-K-103RE 9
1-1/4 023168 P2B-K-104R 023190 P2B-K-104RE 9
1-7/16 023170 P2B-K-107R 023192 P2B-K-107RE 11
1-1/2 023171 P2B-K-108R 023193 P2B-K-108RE 15
1-5/8 023172 P2B-K-110R 023194 P2B-K-110RE 14
1-11/16 023173 P2B-K-111R 023195 P2B-K-111RE 14
1-3/4 023174 P2B-K-112R 023196 P2B-K-112RE 20
1-15/16 023175 P2B-K-115R 023197 P2B-K-115RE 19
2 023176 P2B-K-200R 023198 P2B-K-200RE 19
2-3/16 023177 P2B-K-203R 023199 P2B-K-203RE 24
2-1/4 023178 P2B-K-204R 023200 P2B-K-204RE 28
2-7/16 023179 P2B-K-207R 023201 P2B-K-207RE 28
2-1/2 023180 P2B-K-208R 023202 P2B-K-208RE 28
2-11/16 023181 P2B-K-211R 023203 P2B-K-211RE 40
2-3/4 023182 P2B-K-212R 023204 P2B-K-212RE 40
2-15/16 023183 P2B-K-215R 023205 P2B-K-215RE 39
3 023184 P2B-K-300R 023206 P2B-K-300RE 39
3-7/16 023186 P2B-K-307R 023208 P2B-K-307RE 67
3-1/2 023187 P2B-K-308R 023209 P2B-K-308RE 66
3-15/16 023188 P4B-K-315R 023210 P4B-K-315RE 106

Special Duty hinged cap pillow block – inch
2-bolt

Pillow block assembly – Non-expansion Pillow block assembly – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
1-3/8 067054 P2B-HC-106 20 067055 P2B-HC-106E 20
1-7/16 067050 P2B-HC-107 20 067051 P2B-HC-107E 20
1-1/2 067056 P2B-HC-108 20 067057 P2B-HC-108E 20
1-11/16 067048 P2B-HC-111 27 067049 P2B-HC-111E 27
1-3/4 067042 P2B-HC-112 27 067043 P2B-HC-112E 27
1-15/16 067052 P2B-HC-115 36 067053 P2B-HC-115E 36
2 067060 P2B-HC-200 36 067061 P2B-HC-200E 36
2-3/16 067046 P2B-HC-203 47 067047 P2B-HC-203E 47
2-7/16 067044 P2B-HC-207 60 067045 P2B-HC-207E 60
2-15/16 067072 P2B-HC-215 60 067073 P2B-HC-215E 60
3 067070 P2B-HC-300 60 067071 P2B-HC-300E 60

Type E pillow block – metric
2-bolt

Size (mm) Part number Description Weight (lbs)
35 023620 P2B-E-035MR 7
40 023621 P2B-E-040MR 10
45 023622 P2B-E-045MR 12
50 023623 P2B-E-050MR 12
55 023624 P2B-E-055MR 15
60 023625 P2B-E-060MR 20
65 023626 P2B-E-065MR 20
70 023627 P2B-E-070MR 29
75 023628 P2B-E-075MR 27
80 023629 P2B-E-080MR 49
85 023630 P2B-E-085MR 47
90 023631 P2B-E-090MR 45

Type E pillow block – metric
4-bolt

Size (mm) Part number Description Weight (lbs)
100 023632 P4B-E-100MR 69
110 023633 P4B-E-110MR 85
115 023634 P4B-E-115MR 91
125 023635 P4B-E-125MR 136
135 023636 P4B-E-135MR 245
140 023637 P4B-E-140MR 240
150 023638 P4B-E-150MR 235
160 023639 P4B-E-160MR 355
170 023640 P4B-E-170MR 345
180 023641 P4B-E-180MR 345



Type E flange – inch
4-bolt

Gray Iron
Size (inches) Part number Description Weight (lbs)
1-3/16 023093 F4B-E-103R 4
1-1/4 023094 F4B-E-104R 4
1-3/8 023095 F4B-E-106R 7
1-7/16 023096 F4B-E-107R 7
1-1/2 023097 F4B-E-108R 11
1-5/8 023098 F4B-E-110R 11
1-11/16 023099 F4B-E-111R 11
1-3/4 023100 F4B-E-112R 12
1-7/8 023101 F4B-E-114R 12
1-15/16 023102 F4B-E-115R 12
2 023103 F4B-E-200R 12
2-3/16 023104 F4B-E-203R 15
2-1/4 023105 F4B-E-204R 21
2-7/16 023106 F4B-E-207R 20
2-1/2 023107 F4B-E-208R 19
2-11/16 023108 F4B-E-211R 28
2-3/4 023109 F4B-E-212R 28
2-15/16 023110 F4B-E-215R 27
3 023111 F4B-E-300R 26
3-3/16 023112 F4B-E-303R 52
3-1/4 023113 F4B-E-304R 51
3-7/16 023114 F4B-E-307R 50
3-1/2 023115 F4B-E-308R 50
3-15/16 023116 F4B-E-315R 75
4 023117 F4B-E-400R 75
4-7/16 023118 F4B-E-407R 90
4-1/2 023119 F4B-E-408R 90

Type E-Xtra Piloted Flange – inch
4-bolt

Gray Iron
Size (inches) Part number Description Weight (lbs)
1-3/16 023120 FC-E-103R 5
1-1/4 023121 FC-E-104R 5
1-3/8 023122 FC-E-106R 7
1-7/16 023123 FC-E-107R 6
1-1/2 023124 FC-E-108R 10
1-5/8 023125 FC-E-110R 9
1-11/16 023126 FC-E-111R 9
1-3/4 023127 FC-E-112R 11
1-7/8 023128 FC-E-114R 10
1-15/16 023129 FC-E-115R 10
2 023130 FC-E-200R 10
2-3/16 023131 FC-E-203R 14
2-1/4 023132 FC-E-204R 18
2-7/16 023133 FC-E-207R 18
2-1/2 023134 FC-E-208R 17
2-11/16 023135 FC-E-211R 27
2-3/4 023136 FC-E-212R 27
2-15/16 023137 FC-E-215R 25
3 023138 FC-E-300R 25
3-3/16 023139 FC-E-303R 44
3-1/4 023140 FC-E-304R 44
3-7/16 023141 FC-E-307R 43
3-1/2 023142 FC-E-308R 42
3-15/16 023143 FC-E-315R 59
4 023144 FC-E-400R 58
4-7/16 023145 FC-E-407R 110
4-1/2 023146 FC-E-408R 110
4-15/16 023147 FC-E-415R 130
5 023148 FC-E-500R 130

Type EXL Flange – Inch
4-bolt

Size (inches) Part No. Non-Expansion Description Weight (lbs) Part No. Expansion Description Weight (lbs)
1-3/16 077301 F4B-EXL-103R 6 077326 F4B-EXL-103RE 6
1-1/4 077302 F4B-EXL-104R 6 077327 F4B-EXL-104RE 6
1-3/8 077303 F4B-EXL-106R 8 077328 F4B-EXL-106RE 8
1-7/16 077304 F4B-EXL-107R 8 077329 F4B-EXL-107RE 8
1-1/2 077305 F4B-EXL-108R 13 077330 F4B-EXL-108RE 13
1-5/8 077306 F4B-EXL-110R 13 077331 F4B-EXL-110RE 13
1-11/16 077307 F4B-EXL-111R 13 077332 F4B-EXL-111RE 13
1-3/4 077308 F4B-EXL-112R 15 077333 F4B-EXL-112RE 15
1-7/8 077309 F4B-EXL-114R 15 077334 F4B-EXL-114RE 15
1-15/16 077310 F4B-EXL-115R 15 077335 F4B-EXL-115RE 15
2 077311 F4B-EXL-200R 15 077336 F4B-EXL-200RE 15
2-3/16 077312 F4B-EXL-203R 19 077337 F4B-EXL-203RE 19
2-1/4 077313 F4B-EXL-204R 24 077338 F4B-EXL-204RE 24
2-7/16 077314 F4B-EXL-207R 24 077339 F4B-EXL-207RE 24
2-1/2 077315 F4B-EXL-208R 24 077340 F4B-EXL-208RE 24
2-11/16 077316 F4B-EXL-211R 35 077341 F4B-EXL-211RE 35
2-3/4 077317 F4B-EXL-212R 35 077342 F4B-EXL-212RE 35
2-15/16 077318 F4B-EXL-215R 35 077343 F4B-EXL-215RE 35
3 077319 F4B-EXL-300R 35 077344 F4B-EXL-300RE 35
3-3/16 077320 F4B-EXL-303R 61 077345 F4B-EXL-303RE 61
3-1/4 077321 F4B-EXL-304R 61 077346 F4B-EXL-304RE 61
3-7/16 077322 F4B-EXL-307R 61 077347 F4B-EXL-307RE 61
3-1/2 077323 F4B-EXL-308R 61 077348 F4B-EXL-308RE 61
3-15/16 077324 F4B-EXL-315R 90 077349 F4B-EXL-315RE 90
4 077325 F4B-EXL-400R 90 077350 F4B-EXL-400RE 90

Double Interlock flange – inch
4-bolt, square and round

Ductile iron – Non-expansion Ductile iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
1-3/16 023422 F4B-DI-103R 7 023451 F4B-DI-103RE 7
1-1/4 023423 F4B-DI-104R 7 023452 F4B-DI-104RE 7
1-3/8 023424 F4B-DI-106R 10 023453 F4B-DI-106RE 10
1-7/16 023425 F4B-DI-107R 9 023454 F4B-DI-107RE 9
1-1/2 023426 F4B-DI-108R 14 023455 F4B-DI-108RE 14
1-5/8 023427 F4B-DI-110R 14 023456 F4B-DI-110RE 14
1-11/16 023428 F4B-DI-111R 13 023457 F4B-DI-111RE 13
1-3/4 023429 F4B-DI-112R 16 023458 F4B-DI-112RE 16
1-7/8 023430 F4B-DI-114R 16 023459 F4B-DI-114RE 16
1-15/16 023431 F4B-DI-115R 16 023460 F4B-DI-115RE 16
2 023432 F4B-DI-200R 15 023461 F4B-DI-200RE 15
2-3/16 023433 F4B-DI-203R 19 023462 F4B-DI-203RE 19
2-1/4 023434 F4B-DI-204R 23 023463 F4B-DI-204RE 23
2-7/16 023435 F4B-DI-207R 22 023464 F4B-DI-207RE 22
2-1/2 023436 F4B-DI-208R 22 023465 F4B-DI-208RE 22
2-11/16 023437 F4B-DI-211R 34 023466 F4B-DI-211RE 34
2-3/4 023438 F4B-DI-212R 33 023467 F4B-DI-212RE 33
2-15/16 023439 F4B-DI-215R 31 023468 F4B-DI-215RE 31
3 023440 F4B-DI-300R 31 023469 F4B-DI-300RE 31
3-3/16 023441 F4B-DI-303R 54 023470 F4B-DI-303RE 54
3-1/4 023442 F4B-DI-304R 53 023471 F4B-DI-304RE 53
3-7/16 023443 F4B-DI-307R 52 023472 F4B-DI-307RE 52
3-1/2 023444 F4B-DI-308R 52 023473 F4B-DI-308RE 52
3-15/16 023445 F4B-DI-315R 82 023474 F4B-DI-315RE 82
4 023446 F4B-DI-400R 81 023475 F4B-DI-400RE 81
4-7/16 023447 F4B-DI-407R 158 023476 F4B-DI-407RE 158
4-1/2 023448 F4B-DI-408R 158 023477 F4B-DI-408RE 158
4-15/16 023449 F4B-DI-415R 257 023478 F4B-DI-415RE 271
5 023450 F4B-DI-500R 329 023479 F4B-DI-500RE 329

Non-expansion furnished unless otherwise specified.
◊ 4-7/16”— 5” Housings are made of cast iron.

Type K Flange Bearing – Inch
4-bolt

Ductile iron – Non-expansion Ductile iron – Expansion
Size (inches) Part number Description Part number Description Weight (lbs)
1-3/16 023211 F4B-K-103R 023233 F4B-K-103RE 6
1-1/4 023212 F4B-K-104R 023234 F4B-K-104RE 6
1-3/8 023213 F4B-K-106R 023235 F4B-K-106RE 7
1-7/16 023214 F4B-K-107R 023236 F4B-K-107RE 8
1-1/2 023215 F4B-K-108R 023237 F4B-K-108RE 12
1-5/8 023216 F4B-K-110R 023238 F4B-K-110RE 12
1-11/16 023217 F4B-K-111R 023239 F4B-K-111RE 12
1-3/4 023218 F4B-K-112R 023240 F4B-K-112RE 13
1-15/16 023219 F4B-K-115R 023241 F4B-K-115RE 15
2 023220 F4B-K-200R 023242 F4B-K-200RE 14
2-3/16 023221 F4B-K-203R 023243 F4B-K-203RE 17
2-1/4 023222 F4B-K-204R 023244 F4B-K-204RE 17
2-7/16 023223 F4B-K-207R 023245 F4B-K-207RE 20
2-1/2 023224 F4B-K-208R 023246 F4B-K-208RE 20
2-11/16 023225 F4B-K-211R 023247 F4B-K-211RE 24
2-3/4 023226 F4B-K-212R 023248 F4B-K-212RE 24
2-15/16 023227 F4B-K-215R 023249 F4B-K-215RE 29
3 023228 F4B-K-300R 023250 F4B-K-300RE 29
3-3/16 023229 F4B-K-303R 023251 F4B-K-303RE 45
3-7/16 023230 F4B-K-307R 023252 F4B-K-307RE 47
3-1/2 023231 F4B-K-308R 023253 F4B-K-308RE 45
3-15/16 023232 F4B-K-315R 023254 F4B-K-315RE 73


Type C flange – inch
4-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
1-7/16 104040 F4B-C-107 21 104050 F4B-C-107E 21
1-11/16 104041 F4B-C-111 31 104051 F4B-C-111E 31
1-3/4 104106 F4B-C-112 31 104078 F4B-C-112E 31
1-15/16 104042 F4B-C-115 37 104052 F4B-C-115E 38
2-3/16 104043 F4B-C-203 49 104053 F4B-C-203E 49
2-7/16 104044 F4B-C-207 63 104054 F4B-C-207E 63
2-15/16 104045 F4B-C-215 98 104055 F4B-C-215E 98
3 104119 F4B-C-300 140 104090 F4B-C-300E 140
3-7/16 104046 F4B-C-307 140 104056 F4B-C-307E 140

Special Duty flange – inch
4-bolt

Gray iron – Non-expansion Gray iron – Expansion
Size (inches) Part number Description Weight (lbs) Part number Description Weight (lbs)
1-7/16 104020 F4B-SD-107 21 104030 F4B-SD-107E 22
1-1/2 104161 F4B-SD-108 21 104196 F4B-SD-108E 22
1-11/16 104021 F4B-SD-111 30 104031 F4B-SD-115E 30
1-3/4 104162 F4B-SD-112 30 104197 F4B-SD-112E 30
1-15/16 104022 F4B-SD-115 37 104032 F4B-SD-115E 37
2 104164 F4B-SD-200 37 104199 F4B-SD-200E 37
2-3/16 104023 F4B-SD-203 46 104033 F4B-SD-203E 49
2-3/8 104169 F4B-SD-206 62 104204 F4B-SD-206E 64
2-7/16 104024 F4B-SD-207 62 104034 F4B-SD-207E 64
2-1/2 104170 F4B-SD-208 62 104205 F4B-SD-208E 64
2-11/16 104172 F4B-SD-211 85 104207 F4B-SD-211E 88
2-3/4 104173 F4B-SD-212 83 104208 F4B-SD-212E 86
2-15/16 104025 F4B-SD-215 81 104035 F4B-SD-215E 85
3 104176 F4B-SD-300 81 104211 F4B-SD-300E 84
3-3/16 104177 F4B-SD-303 141 104212 F4B-SD-303E 145
3-7/16 104026 F4B-SD-307 139 104036 F4B-SD-307E 144
3-1/2 104181 F4B-SD-308 138 104216 F4B-SD-308E 143
3-15/16 104027 F4B-SD-315 230 104037 F4B-SD-315E 234
4 104010 F4B-SD-400 229 104003 F4B-SD-400E 234
4-7/16 104028 F4B-SD-407 325 104038 F4B-SD-407E 325
4-15/16 104029 F4B-SD-415 430 104039 F4B-SD-415E 430
5 104013 F4B-SD-500 428 104006 F4B-SD-500E 428
5-15/16 104016 F4B-SD-515 560 104017 F4B-SD-515E 560
6 104018 F4B-SD-600 560 104019 F4B-SD-600E 560



Type E-Xtra Wide-slot Take-Up Unit

Gray Iron
Size (inches) Part number Description Weight (lbs) Frame
1-3/8 023076 WSTU-E-106R 8 CP308
1-7/16 023077 WSTU-E-107R 8 CP308
1-1/2 023078 WSTU-E-108R 10 CP308
1-5/8 023079 WSTU-E-110R 10 CP400
1-11/16 023080 WSTU-E-111R 10 CP400
1-3/4 023081 WSTU-E-112R 12 CP400
1-7/8 023082 WSTU-E-114R 12 CP400
1-15/16 023083 WSTU-E-115R 12 CP400
2 023084 WSTU-E-200R 12 CP400
2-3/16 023085 WSTU-E-203R 16 CP408
2-1/4 023086 WSTU-E-204R 21 CP502
2-7/16 023087 WSTU-E-207R 21 CP502
2-1/2 023088 WSTU-E-208R 21 CP502
2-11/16 023089 WSTU-E-211R 30 CP515
2-3/4 023090 WSTU-E-212R 30 CP515
2-15/16 023091 WSTU-E-215R 30 CP515
3 023092 WSTU-E-300R 30 CP515

Type K take-up – inch
Wide-slot (WS)

Size (inches) Part number Description Weight (lbs) Frame
1-7/16 023256 WSTU-K-107R 8 CP308
1-15/16 023261 WSTU-K-115R 11 CP400
2-3/16 023263 WSTU-K-203R 15 CP408
2-7/16 023265 WSTU-K-207R 20 CP502
2-1/2 023266 WSTU-K-208R 20 CP502
2-15/16 023269 WSTU-K-215R 28 CP515
3 023270 WSTU-K-300R 28 CP515

Type E-Xtra TP Take-Up Bearing– inch

Gray Iron
Size (inches) Part number Description Weight (lbs) Frame size ref.
1-3/4 023149 TP-E-112R 14 TP10
1-7/8 023150 TP-E-114R 14 TP10
1-15/16 023151 TP-E-115R 14 TP10
2 023152 TP-E-200R 14 TP10
2-3/16 023153 TP-E-203R 16 TP20
2-1/4 023154 TP-E-204R 21 TP30
2-7/16 023155 TP-E-207R 21 TP30
2-1/2 023156 TP-E-208R 21 TP30
2-11/16 023157 TP-E-211R 29 TP40
2-3/4 023158 TP-E-212R 29 TP40
2-15/16 023159 TP-E-215R 29 TP40
3 023160 TP-E-300R 29 TP40
3-3/16 023161 TP-E-303R 43 TP50
3-1/4 023162 TP-E-304R 43 TP50
3-7/16 023163 TP-E-307R 42 TP50
3-1/2 023164 TP-E-308R 42 TP50
3-15/16 023165 TP-E-315R 62 TP60
4 023166 TP-E-400R 62 TP60

Type K take-up – inch
Top-angle (TP)

Size (inches) Part number Description Weight (lbs)
1-15/16 023314 TP-K-115R 13
2-3/16 023316 TP-K-203R 16
2-7/16 023318 TP-K-207R 20
2-15/16 023322 TP-K-215R 27
3-7/16 023325 TP-K-307R 40
3-15/16 023327 TP-K-315R 59

Type EXL S-1 Unit

Size (inches) Part number Description Weight (lbs)
1-3/16 077192 S1U-EXL-103R 3
1-1/4 077193 S1U-EXL-104R 3
1-3/8 077194 S1U-EXL-106R 4
1-7/16 077195 S1U-EXL-107R 4
1-1/2 077196 S1U-EXL-108R 4
1-5/8 077197 S1U-EXL-110R 6
1-11/16 077198 S1U-EXL-111R 6
1-3/4 077199 S1U-EXL-112R 6
1-7/8 077200 S1U-EXL-114R 6
1-15/16 077201 S1U-EXL-115R 7
2 077202 S1U-EXL-200R 7
2-3/16 077203 S1U-EXL-203R 9
2-1/4 077204 S1U-EXL-204R 11
2-7/16 077205 S1U-EXL-207R 11
2-1/2 077206 S1U-EXL-208R 11
2-11/16 077207 S1U-EXL-211R 16
2-3/4 077208 S1U-EXL-212R 16
2-15/16 077209 S1U-EXL-215R 16
3 077210 S1U-EXL-300R 16
3-3/16 077211 S1U-EXL-303R 30
3-1/4 077212 S1U-EXL-304R 30
3-7/16 077213 S1U-EXL-307R 30
3-1/2 077214 S1U-EXL-308R 30
3-15/16 077215 S1U-EXL-315R 42
4 077216 S1U-EXL-400R 42
4-7/16 077217 S1U-EXL-407R 56
4-1/2 077218 S1U-EXL-408R 56
4-15/16 077219 S1U-EXL-415R 81
5 077220 S1U-EXL-500R 81

TAF Inner Unit – Inch
S1U cartridge

Size (inches) Part number Description Weight (lbs)
1-7/16 037632 S1U509-TAF-107 5
1-11/16 037633 S1U510-TAF-111 7
1-15/16 037634 S1U511-TAF-115 8
2-3/16 037635 S1U513-TAF-203 9
2-7/16 037636 S1U515-TAF-207 11
2-1/2 037637 S1U515-TAF-208 11
2-11/16 037638 S1U516-TAF-211 18
2-3/4 037639 S1U516-TAF-212 17
2-15/16 037640 S1U517-TAF-215 17
3 037641 S1U517-TAF-300 17
3-7/16 037642 S1U520-TAF-307 31
3-1/2 037643 S1U520-TAF-307 31
3-15/16 037644 S1U522-TAF-315 43
4 037645 S1U522-TAF-400 43
4-7/16 037646 S1U526-TAF-407 57
4-1/2 037647 S1U526-TAF-408 68
4-15/16 037648 S1U528-TAF-415 82
5 037649 S1U528-TAF-500 82
5-7/16 023610 S1U532-TAF-507 155
5-15/16 023611 S1U534-TAF-515 143
6 023612 S1U534-TAF-600 138
6-7/16 023613 S1U536-TAF-607 187
6-1/2 023614 S1U536-TAF-608 182
6-15/16 023615 S1U538-TAF-615 180
7 023616 S1U538-TAF-700 178

Double Interlock inner unit – inch
S-1 units – Gray iron

Size (inches) Part number Description Weight (lbs)
1-3/16 023507 S1U-DI-103R 3
1-1/4 023508 S1U-DI-104R 4
1-3/8 023509 S1U-DI-106R 5
1-7/16 023510 S1U-DI-107R 5
1-1/2 023511 S1U-DI-108R 7
1-5/8 023512 S1U-DI-110R 7
1-11/16 023513 S1U-DI-111R 7
1-3/4 023514 S1U-DI-112R 8
1-7/8 023515 S1U-DI-114R 8
1-15/16 023516 S1U-DI-115R 8
2 023517 S1U-DI-200R 8
2-3/16 023518 S1U-DI-203R 10
2-1/4 023519 S1U-DI-204R 12
2-7/16 023520 S1U-DI-207R 11
2-1/2 023521 S1U-DI-208R 11
2-11/16 023522 S1U-DI-211R 18
2-3/4 023523 S1U-DI-212R 17
2-15/16 023524 S1U-DI-215R 17
3 023525 S1U-DI-300R 17
3-3/16 023526 S1U-DI-303R 34
3-1/4 023527 S1U-DI-304R 31
3-7/16 023528 S1U-DI-307R 31
3-1/2 023529 S1U-DI-308R 31
3-15/16 023530 S1U-DI-315R 43
4 023531 S1U-DI-400R 43
4-7/16 023532 S1U-DI-407R 57
4-1/2 023533 S1U-DI-408R 64
4-15/16 023534 S1U-DI-415R 82
5 023535 S1U-DI-500R 82
5-7/16 023536 S1U-DI-507R 159
5-15/16 023537 S1U-DI-515R 135
6 023538 S1U-DI-600R 128
6-7/16 023539 S1U-DI-607R 187
6-1/2 023540 S1U-DI-608R 182
6-15/16 023541 S1U-DI-615R 180
7 023542 S1U-DI-700R 178

Double Interlock – metric
S-1 inner unit

Size (mm) Part number Description Weight (lbs)
35 023700 S1U-DI-035M 5
40 023701 S1U-DI-040M 6
45 023702 S1U-DI-045M 8
50 023703 S1U-DI-050M 8
55 023704 S1U-DI-055M 10
60 023705 S1U-DI-060M 11
65 023706 S1U-DI-065M 10
70 023707 S1U-DI-070M 17
75 023708 S1U-DI-075M 17
80 023709 S1U-DI-080M 33
85 023710 S1U-DI-085M 32
90 023711 S1U-DI-090M 31
100 023712 S1U-DI-100M 42
110 023713 S1U-D1-110M 55
115 023714 S1U-DI-115M 71
125 023715 S1U-DI-125M 85

Type K inner unit – inch

Size (inches) Part number Description Part number Description Weight (lbs)
1-3/16 023271 S1U-K-103R — B1U-K-103R 3
1-1/4 023272 S1U-K-104R — B1U-K-104R 3
1-3/8 023273 S1U-K-106R 023293 B1U-K-106R 4
1-7/16 023274 S1U-K-107R 023294 B1U-K-107R 4
1-1/2 023275 S1U-K-108R 023295 B1U-K-108R 5
1-5/8 023276 S1U-K-110R 023296 B1U-K-110R 5
1-11/16 023277 S1U-K-111R 023297 B1U-K-111R 5
1-3/4 023278 S1U-K-112R 023298 B1U-K-112R 7
1-15/16 023279 S1U-K-115R 023299 B1U-K-115R 7
2 023280 S1U-K-200R 023300 B1U-K-200R 7
2-3/16 023281 S1U-K-203R 023301 B1U-K-203R 9
2-1/4 023282 S1U-K-204R 023302 B1U-K-204R 11
2-7/16 023283 S1U-K-207R 023303 B1U-K-207R 11
2-1/2 023284 S1U-K-208R 023304 B1U-K-208R 11
2-11/16 023285 S1U-K-211R 023305 B1U-K-211R 15
2-3/4 023286 S1U-K-212R 023306 B1U-K-212R 15
2-15/16 023287 S1U-K-215R 023307 B1U-K-215R 15
3 023288 S1U-K-300R 023308 B1U-K-300R 15
3-3/16 023289 S1U-K-303R 023309 B1U-K-303R 28
3-7/16 023290 S1U-K-307R 023310 B1U-K-307R 28
3-1/2 023291 S1U-K-308R 023311 B1U-K-308R 28
3-15/16 023292 S1U-K-315R 023312 B1U-K-315R 40

Type C inner unit – inch

D Units S-1 Units B-1 Units
Size (inches) Part number Description Part number Description Part number Description Weight (lbs)
1-7/16 065282 DU-C-107 087199 S1U-C-107 069060 B1U-C-107 7
1-1/2 065258 DU-C-108 087205 S1U-C-108 — — 11
1-11/16 065283 DU-C-111 087200 S1U-C-111 069061 B1U-C-111 11
1-3/4 065260 DU-C-112 087207 S1U-C-112 — — 11
1-15/16 065284 DU-C-115 087194 S1U-C-115 069062 B1U-C-115 12
2 065262 DU-C-200 087209 S1U-C-200 069034 B1U-C-200 18
2-3/16 065285 DU-C-203 087195 S1U-C-203 069063 B1U-C-203 17
2-1/4 065265 DU-C-204 087215 S1U-C-204 — — 17
2-7/16 065286 DU-C-207 087196 S1U-C-207 069064 B1U-C-207 20
2-1/2 — — — — 069039 B1U-C-208 35
2-11/16 065268 DU-C-211 087218 S1U-C-211 — — 34
2-7/8 065270 DU-C-214 087220 S1U-C-214 — — 34
2-15/16 065287 DU-C-215 087197 S1U-C-215 069065 B1U-C-215 34
3 065271 DU-C-300 087221 S1U-C-300 — — 55
3-3/16 — — 087222 S1U-C-303 069045 B1U-C-303 53
3-1/4 — — — — 069046 B1U-C-304 53
3-7/16 065288 DU-C-307 087198 S1U-C-307 069066 B1U-C-307 51
3-1/2 065274 DU-C-308 087224 S1U-C-308 — — 115
3-11/16 — — 087225 S1U-C-311 — — 115
3-15/16 065304 DU-C-315 087210 S1U-C-315 069067 B1U-C-315 115
4 — — — — 069069 B1U-C-400 115
4-7/16 065305 DU-C-407 087211 S1U-C-407 — — 138
4-15/16 065306 DU-C-415 087212 S1U-C-415 — — 190

Special Duty inner unit – inch

D Units S-1 Units B-1 Units
Size (inches) Part number Description Part number Description Part number Description Weight (lbs)
1-3/8 066445 DU-SD-106 066500 S1U-SD-106 066560 B1U-SD-106 7
1-7/16 066280 DU-SD-107 066290 S1U-SD-107 066315 B1U-SD-107 7
1-1/2 066446 DU-SD-108 066501 S1U-SD-108 066561 B1U-SD-108 7
1-9/16 066444 DU-SD-109 066499 S1U-SD-109 066559 B1U-SD-109 10
1-5/8 066324 DU-SD-110 066312 S1U-SD-110 066314 B1U-SD-110 10
1-11/16 066281 DU-SD-111 066291 S1U-SD-111 066316 B1U-SD-111 10
1-3/4 066447 DU-SD-112 066502 S1U-SD-112 066562 B1U-SD-112 10
1-7/8 066448 DU-SD-114 066503 S1U-SD-114 066563 B1U-SD-114 12
1-15/16 066282 DU-SD-115 066292 S1U-SD-115 066317 B1U-SD-115 12
2 066464 DU-SD-200 066504 S1U-SD-200 066564 B1U-SD-200 12
2-1/8 066450 DU-SD-202 066506 S1U-SD-202 066566 B1U-SD-202 16
2-3/16 066283 DU-SD-203 066293 S1U-SD-203 066318 B1U-SD-203 16
2-7/16 066284 DU-SD-207 066294 S1U-SD-207 066319 B1U-SD-207 20
2-15/16 066286 DU-SD-215 066295 S1U-SD-215 066320 B1U-SD-215 29
3 066459 DU-SD-300 066515 S1U-SD-300 066576 B1U-SD-300 29
3-7/16 066287 DU-SD-307 066296 S1U-SD-307 066321 B1U-SD-307 47
4 066469 DU-SD-400 066524 S1U-SD-400 066585 B1U-SD-400 94
5 066472 DU-SD-500 066527 S1U-SD-500 066590 B1U-SD-500 175
6 066476 DU-SD-600 066531 S1U-SD-600 066594 B1U-SD-600 300

Double Interlock inner unit – inch
D units – Gray iron

Size (inches) Part number Description Weight (lbs)
1-3/16 — DU-DI-103R —
1-1/4 — DU-DI-104R —
1-3/8 023480 DU-DI-106R 5
1-7/16 023481 DU-DI-107R 5
1-1/2 023482 DU-DI-108R 8
1-5/8 023483 DU-DI-110R 7
1-11/16 023484 DU-DI-111R 7
1-3/4 023485 DU-DI-112R 8
1-7/8 023486 DU-DI-114R 8
1-15/16 023487 DU-DI-115R 8
2 023488 DU-DI-200R 8
2-3/16 023489 DU-DI-203R 9
2-1/4 023490 DU-DI-204R 12
2-7/16 023491 DU-DI-207R 12
2-1/2 023492 DU-DI-208R 12
2-11/16 023493 DU-DI-211R 18
2-3/4 023494 DU-DI-212R 17
2-15/16 023495 DU-DI-215R 16
3 023496 DU-DI-300R 16
3-3/16 023497 DU-DI-303R 32
3-1/4 023498 DU-DI-304R 31
3-7/16 023499 DU-DI-307R 30
3-1/2 023500 DU-DI-308R 29
3-15/16 023501 DU-DI-315R 46
4 023502 DU-DI-400R 43
4-7/16 023503 DU-DI-407R 57
4-1/2 023504 DU-DI-408R 64
4-15/16 023505 DU-DI-415R 85
5 023506 DU-DI-500R 85

Double Interlock inner unit – inch
B-1 units – Gray iron

Size (inches) Part number Description Weight (lbs)
1-3/16 023543 BIU-DI-103R 3
1-3/8 023545 BIU-DI-106R 5
1-7/16 023546 BIU-DI-107R 5
1-1/2 023547 BIU-DI-108R 6
1-5/8 023548 BIU-DI-110R 6
1-3/4 023550 BIU-DI-112R 8
1-15/16 023552 BIU-DI-115R 8
2 023553 BIU-DI-200R 7
2-3/16 023554 BIU-DI-203R 9
2-7/16 023556 BIU-DI-207R 12
2-1/2 023557 BIU-DI-208R 11
2-11/16 023558 BIU-DI-211R 17
2-3/4 023559 BIU-DI-212R 17
2-15/16 023560 BIU-DI-215R 17
3 023561 BIU-DI-300R 17
3-7/16 023564 BIU-DI-307R 30
3-1/2 023565 BIU-DI-308R 30
3-15/16 023566 BIU-DI-315R 45
4 023567 BIU-DI-400R 44
4-7/16 023568 BIU-DI-407R 58
4-1/2 023569 BIU-DI-408R 64
4-15/16 023570 BIU-DI-415R 87
5 023571 BIU-DI-500R 86
